Inspecting Fiber Ends
Fiber Inspection Probe 37
Capturing Images
In multiple-fiber connector mode, continue capturing files until you have
reached the number set in the user preferences. At the end of the capture,
you will be prompted to save your file. You can also save the file at any
time, even if you have not reached the maximum incremental value set.
While capturing the files, you can browse through the acquisitions you
have made. You will notice that the Video Control button becomes a
Navigation button.
To browse through the multiple-fiber connector acquisitions:
1. From the main window, click the Navigation button.
2. Use the arrow buttons to browse through the acquired files, or use the
drop-down menu to go directly to a specific acquisition.
