Opening and closing files – EXFO FIP-400 Fiber Inspection Probe and ConnectorMax User Manual
Page 47
Inspecting Fiber Ends
Fiber Inspection Probe
41
Opening and Closing Files
Opening and Closing Files
You can open captured files directly from the application to view them.
You can either open current .cmax files, or a legacy image file taken from a
previous fiber inspection.
Note: The accepted image formats for legacy files are .bmp, .jpg and .gif.
Note: Sample files for both single-fiber and multiple-fiber test modes are
available under the folder where ConnectorMax was installed, under a
folder named UserSamples.
To open a file:
1. From the main window, select File, and then Open.
2. Select the desired file, and then click Open.
If you are opening a multiple-fiber connector file, you can browse through
the individual files using the Navigation button.
Note: If you are in a file browser, you can also double-click on the file to open it in
ConnectorMax. Double-clicking on a legacy file will open the application
currently associated with this file format.
