Upgrading The Computer
Upgrading the System Memory (RAM) 6 - 7
6
3. Remove the bay cover .
4. Gently pull the two release latches ( & ) on the sides of the memory socket in
the direction indicated by the arrows in Figure 6 - 6 .
14
14
Figure 6 - 5
Bay Cover Removal
Contact Warning
Be careful not to touch
the metal pins on the
module’s connecting
edge. Even the cleanest
hands have oils which
can attract particles, and
degrade the module’s
performance.
Figure 6 - 6
RAM Module
Release
15 16
15 16
