Modules
7 - 14 Mini-PCI TV Tuner Module
7
Mini-PCI TV Tuner Module
You may have one of two optional Mini-PCI TV Tuner modules supplied with your
computer, depending on your purchase configuration. The optional TV Tuner allows
you to watch TV, play music CDs, video conference and capture still images and
video on your PC.
The AverMedia M103 Hybrid (for both analog and digital inputs) or AverMedia
M102 (for analog input only) Mini-PCI TV Tuner Module comes with a remote
control unit and CDs containing the AverTV Utility software & Power DVD soft-
ware.
The TV antenna jack and S-Video-In jack will only be enabled when the TV
Tuner module is installed. Make sure you install any software before connect-
ing the TV antenna.
TV Tuner Remote
Point the remote at the
consumer IR transceiv-
er to change channels
etc.
Figure 7 - 6
TV Tuner Ports
1. Consumer IR
Transceiver
2. S-Video-In Jack
3. TV Antenna Jack
2
1
3
