System Map: Top View with LCD Panel Open
Figure 1 - 2 - Top View with LCD Panel Open
2
5
3
4
1
7
4
8
1. Optional Built-In PC
Camera
2. LCD
3. LED Power &
Communication
Indicators
4. Speakers
5. AP-Key Buttons &
Power Button
6. Built-In Microphone
7. LED Status Indicators
8. Keyboard
9. TouchPad and Buttons
10. Consumer Infrared
Transceiver*
* Enabled with Optional Mini-
PCI TV Tuner Only
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft
is usually prohibited.
Make sure the mod-
ule(s) are OFF if you are
using the computer
aboard aircraft.
The key combination Fn
+ F11 toggles power to
the WLAN module, the
Ap-key
to the Blue-
tooth module.
9
6
10 7
5
