System Map: Front & Rear Views
3 4
1
7
Figure 1 - 4
Front & Rear Views
1. LCD Latches
2. Consumer Infrared
Transceiver
*
3. 7-Pin S-Video-Out
Jack
4. DVI-Out Port
5. DC-In Jack
6. Vent/Fan Intake
7. RJ-11 Phone Jack
8. 2 * USB 2.0 Ports
9. Serial Port
10. S-Video-In Jack *
11. Security Lock Slot
* Enabled with Optional Mini-
PCI TV Tuner Only
Overheating
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)
while the computer is in use.
2
9 8 11
5
10
6
1
7-Pin S-Video-Out Jack
The 7-pin S-Video Out Jack requires an adapter cable (7-pin S-Video plug
to 4-pin S-Video jack adapter) in order to connect to a standard S-Video ca-
ble (the y-cable pictured includes a yellow composite video jack).
3 3
S-Video/Composite Cable HDTV Cable
