System Map: Top View with LCD Panel Open - 13
Concise User’s Guide
Engl
ish
System Map: Top View with LCD Panel Open
Figure 7
Top View with LCD Pan-
el Open
1. Built-In PC Camera
(Optional)
2. LCD
3. Fingerprint Reader
Module (Optional)
4. Menu & Screen Rotation
Buttons
5. Speakers
6. Screen Hinge
7. LED Status Indicators
8. Keyboard
9. TouchPad & Buttons
10. LED Power &
Communication Indicators
11. Power Switch
12. Microphone
3
4
2
5
1
7
8
4
6
9
3
11
10
5
12
Wireless Device
Operation Aboard Aircraft
The use of any portable elec-
tronic transmission devices
aboard aircraft is usually pro-
hibited. Make sure the mod-
ule(s) are OFF if you are
using the computer aboard
aircraft.
Use the appropriate function
key combination (see
Table 3, on page 16 ) to tog-
gle power to the wireless
modules (3.5G/WLAN/Blue-
tooth), and check the LED in-
dicator
/ to see if
the modules are powered on
or not (see
Table 2, on
page 14 ).
