Quick Start Guide
LED Indicators 1 - 7
1
LED Indicators
The LED indicators on the top case and front of the
computer display helpful information about the cur-
rent status of the computer.
Table 1 - 1 - Top Case LED Indicators
Table 1 - 2 - Front Case LED Indicators
Icon Color Description
Blue
Number Lock is Activated (press Fn + Num Lk)
Blue
Caps Lock is Activated (press Caps Lock)
Blue
Scroll Lock is Activated (press Fn + Scr Lk)
Icon Color Description
Orange AC/DC Power is Plugged In
Green The Computer is On
Blinking
Green
The Computer is in Sleep Mode
Blinking
Orange
The Powered USB Port is On
(see “Powered USB 3.0 Port” on
page 1 - 13 )
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange
The Battery Has Reached Critically
Low Power Status
Green
Airplane Mode is ON (the WLAN/
Bluetooth/3G Modules are OFF)
Green Hard Disk Activity
