Specifications
D - 4 Specifications
D
A barebone system does not include the CPU,
HDD, RAM, adapter, power cord, VGA card and
factory option modules (weight tolerance within +/-
5%).
(802.11b/g/n) Half Mini-Card PCIe WLAN
+ Bluetooth V4.0+LE Combo Module
(Factory Option)
(802.11b/g/n) Half Mini-Card PCIe WLAN
Module (Factory Option)
UMTS/HSPA+ based 3G Module with
Full Size Mini-Card Interface (Factory
Option)
Quad-band GSM/GPRS (850 MHz, 900
MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Note that UMTS modes CAN NOT be
used in North America
BIOS
One 48Mb SPI Flash ROM
AMI BIOS
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Trusted Platform Module V1.2(Factory
Option)
Operating System
Windows® 8.1
Features
Painted Style for some designs
Intel® Rapid Start Technology
Intel® Smart Response Technology
Indicators
LED Indicators - Power/Suspend,
Battery, HDD, Airplane Mode, Num Lock,
Caps Lock, Scroll Lock, Camera
Power
Full Range AC/DC Adapter – AC in 100 -
240V,
50 - 60Hz DC Output 19.5V, 6.15A
(120 Watts)
Removable 6 Cell Smart Lithium Ion Battery
Pack 62.16WH
Power Management
Supports Wake on LAN
Supports Wake on USB
Supports Wake on RTC Alarm (AC Mode
Only
Environmental Spec
Temperature
Operating: 5
° C - 35 ° C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20%
- 80%
Non-Operating: 10% - 90%
Physical Dimensions & Weight
330mm (w) * 227mm (d) * 31.9mm (h)
2.0kg Barebone System* with 62.16WH
Battery
