Eurocom M4 - Manual (Page 275)

Specifications
Specifications D - 3
D
Storage
One Changeable 2.5", 9.5 mm (h) / 7 mm
(h) SATA (Serial) Hard Disk
mSATA SSD (RAID 0/1) with SATA
Interface
Audio
High Definition Audio
Built-In Microphone
2 Built-In Speakers
Sound Blaster™ Cinema
ANSP™ 3D Sound Technology on
Headphone Output
Keyboard & Pointing Device
Isolated Illuminated Keyboard
Built-In TouchPad (with Multi Gesture and
Scrolling Functionality)
Interface
One USB 2.0 Port
Three USB 3.0 Ports (Including one AC/
DC Powered USB 3.0 Port)
One HDMI™-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One External Monitor Port
One Microphone-In Jack
One Headphone/Speaker-Out Jack
One RJ-45 LAN Jack
One DC-In Jack
Card Reader
Embedded Multi-In-1 Push-Push Card
Reader
- MMC / RSMMC
- SD / Mini SD / SDHC / SDXC
Note: Some of these cards require PC
adapters that are usually supplied with
the cards.
Slots
Three Mini-Card Slots:
Slot 1 for Half Size Mini-Card WLAN
Combo Module with PCIe & USB
Interfaces:
Slot 2 for Full Size Mini-Card mSATA
SSD (Solid State Drive) with SATA
Interface)
Slot 3 for Full Size Mini-Card mSATA
SSD (Solid State Drive) with SATA
Interface) OR Full Size Mini-Card 3G
Module with USB Interface (Factory
Option)
Communication
Built-In 10/100/1000Mb Base-TX Ethernet
LAN
1.0M HD PC Video Camera Module
OR
2.0M FHD PC Video Camera Module
(Factory Option)
Intel® Dual Band Wireless-N 7260 (2*2
802.11 a/g/n) Half Mini-Card PCIe WLAN
+ Bluetooth Combo Module (Factory
Option)
Intel® Wireless-N 7260 (2*2 802.11 b/g/n)
Half Mini-Card PCIe WLAN
+ Bluetooth
Combo Module (Factory Option)
Intel® Dual Band Wireless-AC 7260
(2*2 802.11 a/c) Half Mini-Card PCIe WLAN
+ Bluetooth Combo Module (Factory Op-
tion)
(see over)
