STP-10 Hardware Manual
37
Mating Connectors and Accessories
Mating Connectors
Motor/power supply: PCD P/N ELV06100, included with drive.
IN/OUT1: DB-25 male. Bimba P/N 5-747912-2. Shell Kit Bimba P/N 5-748678-3. Included.
Optional encoder feedback: HD-15 male. Norcomp P/N 180-015-102-001. Shell Kit Bimba P/N 5-748678-1. Not included.
Accessories
Breakout Box for DB-25 Connector
BOB-1, includes cable
Screw Terminal Connectors that mate directly to the DB-25 connector on the front panel of the drive:
Phoenix Contact P/N 2761622.
This connector is not available from Bimba. You must purchase it from a Phoenix distributor.
Mating Cable for IN/OUT connector with “flying leads”
Black Box P/N: BC00702
This cable is not available from Bimba. You must purchase it from Black Box.
Useful for wired applications. This shielded cable has a DB-25 connector on each
end. You can cut off the female end to create a 6 foot “DB-25 to flying lead cable”.
It’ll be easier to wire if you get the cable color chart from Black Box’s web site.
Regeneration Clamp:
Bimba BIM-RGC-050
Power supplies:
Bimba PWR-320A48 (48 VDC, 6.7A)
Bimba PWR-150A24 (24 VDC, 6.3A)
