Page 33
STP-10 Hardware Manual
33
Code
DC Motor
A
B
C
D
E
F
P6
MTR-DC23T-598-S
0.79
0.25
0.23
0.59 1.498/1.502 0.06
P7
MTR-DC23W-598-S
0.79
0.25
0.23
0.59 1.498/1.502 0.06
P8
MTR-DC23T-601-S
0.79
0.25
0.23
0.59 1.498/1.502 0.06
P9
MTR-DC23W-601-S
0.79
0.25
0.23
0.59 1.498/1.502 0.06
A
B
C
D
E
F
G
N
H
H
L
L
M
120" SHIELDED CABLE
Motor Dimensions
OLE-75, -150; No Encoder
Code
DC Motor
A
B
C
D
E
F
E6
MTR-DC23T-598D-S
0.79
0.25
0.23
0.59 1.498/1.502 0.06
E7
MTR-DC23W-598D-S 0.79
0.25
0.23
0.59 1.498/1.502 0.06
E8
MTR-DC23T-601D-S
0.79
0.25
0.23
0.59 1.498/1.502 0.06
E9
MTR-DC23W-601D-S 0.79
0.25
0.23
0.59 1.498/1.502 0.06
A
B
C
D
E
F
G
N
K
P
H
H
L
L
M
120" SHIELDED CABLE
120" ENCODER CABLE
OLE-75, -150; Encoder Version
