Version 7.1 51
ITEM OV-1700 OV-2100 OV-2600 OV-3000 OV26-BF-I
WIDTH x DEPTH 25.5” x 21” 25.5” x 21” 215.5” x 26” 25.5”x 30.5” 25.5” x 26”
HEIGHT ON LEGS 28” 28” 28” 28.75” 20”*
FIREBOX CAPACITY
(CU/FT)
1.7 1.7 2.3 3.1 2.3
EMISSIONS (GR/HR) 4.1 4.1 3.7 2.8 3.7
BTU (cordwood**) 55,000 55,000 65,000 75,000 65,000
WEIGHT (LBS) 295 305 400 410 430
HEATING CAPACITY
(SQ/FT***)
600-1200 600-1200 1000-1800 1500-2500 1000-1800
BURN TIME (LOW
BURN****)
8 hours 8 hours 10 hours 12 hours 10 hours
LOG SIZE 18 inches 18 inches 18 inches 22 inches 18 inches
FLUE DIAMETER 6 inches 6 inches 6 inches 6 inches 6 inches
MOBILE HOME APPROVED YES YES YES YES NO
ASH PAN NO YES YES YES NO
*
Insert height is shorter because it has no legs
** Estimated BTU’S on hardwood test with continued loading.
*** Figures will vary considerably with fuel and conditions.
**** Based on continued burning at low air setting, not recommended as it
causes excess creosote buildup.
CERTIFICATION: These stoves have been tested and listed by E.E.M.C. to EPA standards and
also by ITS/Warnock Hersey to the following standards:
CSA B366.2
ULC 2627
ULC S628
UL 1482
UL 907
APPENDIX A: SPECIFICATIONS
