TABLE 8: MOBILE HOME (minimum) CHIMNEY SYSTEM REQUIRED PARTS
FIGURE 20
ITEM
NUMBER
PART NUMBER
DESCRIPTION
QTY
1
SDP-C-9084
SPARK ARRESTOR CHIMNEY CAP
1
4
SDP-F-9049V
0/12 – 6/12 ADJUSTABLE ROOF FLASHING
1
4 (alternate)
SDP-F-9051V
ROOF FLASHING, Flat (vs. SDP-F-9049V)
1
9/10 (alternate)
SDP-S-9047N + TRIM
CEILING SUPPORT BOX, Flat
1
9/10
SDP-SB-9048AN + TRIM CEILING SUPPORT BOX, Square (vs. SDP-SB-9048AN)
1
2
SDP-P-9121SS
24” CHIMNEY SECTION
2
5 SDP-IS-9946
ATTIC
INSULATION
SHIELD (ONLY IF NEEDED)
1
8
CERAFORM 126
WALL PROTECTION ( IF REQUIRED)
1
3 SDP-SC-9959
STORM
COLLAR
1
6/7
DVL-8646
DOUBLE WALL ADJUSTABLE OR FIXED STOVEPIPE
1/2
11
DVL-8674
CLOSE CLEARANCE ADAPATER (not shown, Fig 12)
2
NOTE: The information provided in TABLE 8 and detailed in FIGURE 20 are for informational
purposes. These chimney system parts may or may not be needed depending on site specific conditions
found in the homeowner’s application. Consult a certified professional and insure that any installation
meets all federal, state, and local building codes. Failure to follow the chimney manufacturer’s
installation instructions will void Country Flame’s product warranty and can have an adverse impact on
the homeowner’s insurance policy. Contact Country Flame or one of its local authorized dealers to
resolve any questions about installation or parts usage.
