CLEARANCES
CONVENTIONAL CLEARANCES
A…Sidewall 9 In. (229 mm)
B…Back Wall 3 In. (75 mm)………………………(Vertical Venting Installation Requires a Min. 3” Inch Clearance from
Combustibles to vent pipe).
C…Corner Wall 3 Inc. (75 mm)………………..........(Vertical Venting Installation Requires a Min 3” Clearance from
Combustibles to vent pipe).
D…Vent Pipe to Wall 3 In. (75mm)……………………(Maintain 3” inch Clearance for all Installations)
E…Floor Protection Front 6 In. (150 mm)
F…Floor Protection Sides 6 In. (150 mm)
HORIZONTAL INSTALLATION
FLOOR PROTECTION
Floor protector must be 3/8” inch
minimum thickness non-combustible
material or equivalent extending
beneath heater and to the
front/side/rear as indicated.
VERTICAL INSTALLATION
CHIMNEY AND CONNECTOR: 3” LISTED PELLET VENT ONLY.
Note: Regardless of stove clearance, vent pipe must always have a 3” inch clearance.
ALCOVE CLEARANCES
MIN. ALCOVE WIDTH 41 In. (1054 mm)
MIN. ALCOVE HEIGHT 47 In. (1194 mm)
MAX. ALCOVE DEPTH 36 In. (914 mm)
WARNING: THE MINIMUM CLEARANCES LISTED ABOVE ARE BASED ON 3” INCH PL LISTED PELLET-
VENT PIPE. IF YOUR APPLIANCE IS NOT PROPERLY INSTALLED A HOUSE FIRE MAY RESULT. PLEASE
FOLLOW THE PIPE MANUFACTURERS INSTRUCTIONS AND LOCAL BUILDING CODES FOR THE
CLEARANCE TO COMBUSTIBLES REQUIRED FOR THE INSTALLATION OF THE VENT PIPE BEING USED.
