MOBILE HOME REQUIREMENTS
SPECIAL MOBILE HOME REQUIREMENTS:
WARNING: DO NOT INSTALL IN A SLEEPING ROOM.
An outside air source must be connected to the stove and can be brought in through the sidewall or
vented crawl space. Flexible or rigid pipe should be used and will connect to the adaptor on the back of
the stove. (See air inlet location below).
CAUTION: When installing the stove in a mobile home, care must be taken not to interfere with the
structural integrity of the mobile home. Floor, wall and ceiling/roof integrity must be maintained. When
installed in a mobile home, this appliance must be grounded to the steel chassis of the frame with 12
gauge or larger diameter wire. This appliance must also be bolted to the floor in compliance with and
according to H.U.D. requirements, unless not required by local authority. The pedestal model comes with
a hole pre-drilled in the base for bolting.
REAR VIEW WITH PEDESTAL
Outside air can be drawn through the floor or through the sidewall.
4.375
16.75
Tolerance plus or
minus ¼”
Rear Exhaust
Air Inlet
9.625
Bolt to floor
