56 Function Block and Operation Theory
3.9 Application Function I/O
PCIe-7350 features eight AFI (Application Function I/O) lines.
These bi-direction digital I/O lines allow you to route I2C, SPI, trig-
ger, event, handshaking, and clock signals to/from the SCSI-
VHDCI I/O connector. The following table lists the supporting func-
tions of AFI lines and the corresponding pin out.
Function Signal I/O AFI0 AFI1 AFI2 AFI3 AFI4 AFI5 AFI6 AFI7
I
2
C Master
SCL O
●
SDA I/O ●
SPI Master
SCLK O
●
SDO O ●
SDI I
●
CS_0 O ●
CS_1 O
●
CS_2 O ●
External

Trigger in
DI-Start I
● ● ● ● ● ● ● ●
DO-Start I ● ● ● ● ● ● ● ●
DI-Pause I
● ● ● ● ● ● ● ●
DO-Pause I ● ● ● ● ● ● ● ●
Trigger out
DI_SW O ● ● ● ● ● ● ● ●
DO_SW O ● ● ● ● ● ● ● ●
Event
PM O ● ● ● ● ● ● ● ●
COS O
● ● ● ● ● ● ● ●
Handshake
DI-REQ I ● ● ● ● ● ● ● ●
DI-ACK O
● ● ● ● ● ● ● ●
DI-TRIG I ● ● ● ● ● ● ● ●
DO-REQ O
● ● ● ● ● ● ● ●
DO-ACK I ● ● ● ● ● ● ● ●
DO-TRIG I
● ● ● ● ● ● ● ●
Clock
DO-SCLK I/O ●
DI-SCLK I/O
●
Table 3-5: PCIe-7350 AFI I/O Configuration
