External Clock I/O Specification
CLK IN (SMB Jack Connector)
Destination
DI or DO sample clock
Input coupling
AC
Input Impedance
50 Ω
Minimum detectable pulse width
8 ns
External sampled clock range
Square Wave
Voltage
0.2 Vpp to 5 Vpp
Frequency
100 KHz - 50 MHz
Duty cycle
40% - 60%
Sine Wave
Voltage
0.2 Vpp to 5 Vpp
Frequency
100 KHz – 50 MHz
CLK OUT (SMB Jack Connector)
Sources
DI or DO sample clock
Source impedance
50 Ω
Logic Levels
(programmable)
The same logic level of AFI I/O
(1.8 V, 2.5 V, or 3.3 V)
Driving Capacity (Max.)
±8 mA at 1.8 V
±16 mA at 2.5 V
±32 mA at 3.3 V
I
2
C Master Specification
Signal
Direction
Pin
SCL
O
AFI0
SDA
I/O
AFI1
Supported clock rate
(programmable)
1.9 kHz -244.14 kHz;
488.28125 kHz / (n + 1); 1 ≤ n ≤ 255
Transfer size of Data
0 - 4 Bytes
Transfer size of Cmd/ Addr
0 - 4 Bytes
Logic families
(programmable)
1.8 V
2.5 V
3.3 V
Input Voltage
Min. V
IH
1.2 V
1.6 V
2.0 V
Max. V
IL
0.63 V
0.7 V
0.8 V
Output Voltage
Min. V
OH
1.6 V
2.3 V
3.1 V
Max. V
OL
0.2 V
0.2 V
0.2 V
