Storage area Network (SaN) arrays

Model

DSN-1100-10

DSN-2100-10

DSN-3200-10

DSN-3400-10

Storage
Feature

Drive Bay

Drive Interface Support

Sata-II

System Memory

256MB to 512MB

(256MB Standard)

256MB to 512MB

(512MB Standard)

Cache Memory

256MB to 1GB

(256MB Standard)

256MB to 4GB

(512MB Standard)

Battery Backup for Cache

Standard (Approximately 72 hours on Full Charge)

Bandwidth

Up to 425MB/s

Up to 850MB/s

Up to 1160MB/s

Storage Capacity

5TB with 1TB HDDs

8TB with 1TB HDDs

15TB with 1TB HDDs

Supported NICs, ISCI
Accelerators and iSCSI HBAs

Intel

Pro 1000Mt & Xt (1gbe)

alacritech

SES2104ET (SNP 9.1.0.1092 & 7.3.1.0)

alacritech

SES2102ET (SNP 9.1.0.1092 & 7.3.1.0)

Qlogic

4010C, 4052C & 4062C

Intel

Pro 1000Mt & Xt (1gbe)

Intel

Pro 1000 CX4 (1GbE)

Myricom 10G-PCIE-8A-C+E (10GbE)

Chelsio

S310X-SR-XFP (10GbE)

Neterion

Xframe® II & Xframe

e (10gbe)

alacritech

SES2104ET (SNP 9.1.0.1092 & 7.3.1.0)

alacritech

SES2102ET (SNP 9.1.0.1092 & 7.3.1.0)

Qlogic

4010C, 4052C & 4062C

Supported operating Systems

windows Vista

32-bit & x64 (Ultimate & Enterprise) with Built-in iSCSI Initiator

Windows Server 2003

32-bit & x64 SP1 (Standard & Enterprise) with v2.07 iSCSI Initiator

Windows Server 2003

R2 32-bit & x64 SP1 (Standard & Enterprise) with v2.07 iSCSI Initiator

windows XP Pro

32-bit & x64 with v2.07 iSCSI Initiator

Windows 2000 Advanced Server

with v1.6 & v2.01 iSCSI Initiator

Red Hat

7.3; Red Hat

Enterprise AS Update 5

SuSe

Enterprise Server 10.2 32-bit (x86); SuSE

Professional 9.3 32-bit & x64

Mac OS X (10.4 & 10.5)

iSCSI Network
Interface

iSCSI Network Interface

Four 1GbE Copper Ports

eight 1gbe Copper Ports

One 10GbE XFP

(XFP sold separately)

Host Interface

iSCSI Draft 20 Compliant Initiator

Connections

1,024 Hosts

CHAP Authentication

Yes

access Control of Management

Yes

iSCSI/TCP/IP Full Hardware
offload

Yes

Jumbo Frame

Yes

IEEE 802.3ad Link Aggregation

Up to Four LAGs

Up to eight Lags

Not applicable

IEEE 802.1Q Virtual LAN (VLAN)

Up to Four 1-to-1

Mapping between IP

Subnet and VLaN

Up to eight 1-to-1 Mapping between IP Subnet and VLaN

Volume & raID

raID Controller

Single-Integrated in aSIC

raID Support

RAID Levels 0, 1, 1+0 and 5

Volumes

1,024 Virtual Volumes (256 Accessible per Initiator)

target Nodes

1,024

Online Capacity Expansion

Yes

Hot-Swappable Drives

Yes

Instant Volume access

Yes

Free Space Defragmentation

Yes

Auto-Detection Failed Drive

Yes

auto-rebuild Spare Drive

Yes

raID Level Migration

Yes

Drive roaming in Power off

Yes (Configured Drives are Not Bay-Specific)

Micro rebuilds

Yes

Storage
Management

embedded IP-based
Management gUI

Create, Mange, Expand and Monitor Storage Pool, Volumes and RAID

Firmware Field Upgradable

Yes

Power

Supply type

1U 200-Watt

Redundant 2U 400-Watt

Redundant 3U 2+1 760-Watt

Input Voltage

100~240 VAC

90~264 VAC (Auto-Switching)

Input Frequency

50~60Hz

47~63Hz

Input Current (Maximum)

8A@100VAC; 4A@240VAC

20A@90VAC; 10A@264VAC

Power Factor Correction

95%@110V, Full Load

Power Consumption (Full
Configuration)

112-Watt

360-Watt

570-Watt

Thermal (Full Configuration)

815 BTU/hour

1,260 BTU/hour

2,000 BTU/hour

environmental

operating temperature

0°C t0 40°C

Storage temperature

-20°C t0 70°C

Operating Humidity

20% to 90% (Non-Condensing)

Storage Humidity

10% to 95% (Non-Condensing)

Physical

Form Factor

tower

2U, 19-inch Rack-Mount

3U, 19-inch Rack-Mount

Dimension (W x D x H)

167 x 273 x 259 mm

438 x 635 x 89 mm

438 x 571 x 133 mm

Weight (Full Configuration)

4.0 kg

20.4 kg

33 kg

Certification

emission

FCC Class A; CE Class A; C-Tick Class A; VCCI Class A

Safety

CSA 60950-1; UL 60950-1; IEC 60950-1; EN 60950-1

Support for higher capacity drives as they are introduced

Please refer to D-Link website for latest support information
