Chassis Switch Selection Matrix
Models DES-7200 Series
General
Maximum Switching Capacity 6-Slot: 192Gbps; 10-Slot: 384Gbps
Passive Backplane Capacity 6-Slot: 800Gbps; 10-Slot: 1600Gbps
Form Factor 6-Slot: 19-inch 15U Rack-Mount
10-Slot: 19-inch 22U Rack-Mount
CPU Engine Slots 6/10-Slot: 2
I/O Module Slots 6-Slot: 4, 10-Slot: 8 (Vertical)
Power Module Slots 2
Max. 10/100BASE-TX Port 0
Max. 10/100BASE-FX Fiber Port 0
Max. 10/100/1000BASE-T Port 6-Slot: 192; 10-Slot: 384
(With 7200-48 or 7200-48P)
Max. SFP Port 6-Slot: 96; 10-Slot: 192
(With 7200-24G or 7200-24G2XGE)
Max. 10-Gigabit XFP Port 6-Slot: 16; 10-Slot 32 (With 7200-4XG)
Power over Ethernet (PoE) 24-Port: 7200-24P; 48-Port: 7200-48P
Layer 2 Features
Jumbo Frame (Size) Yes (9,216Bytes)
802.1D/802.1w/802.1s Spanning Tree Protocol (STP) Yes
Ethernet Ring Protection Switching (E-RPS) Yes (RERP)
Loopback Detection (LBD) No
802.3ad Link Aggregation Yes
Port Mirroring Yes
Layer 2 Multicast
Internet Group Management Protocol (IGMP) Snooping Yes (v1/v2/v3)
Multicast Listener Discover (MLD) Snooping No
Virtual LAN (VLAN)
802.1Q VLAN Tagging Yes
802.1v Protocol VLAN Classification Yes
Double VLAN (Q-in-Q) Yes
IGMP Snooping Multicast (ISM) VLAN Yes (IVGL/SVGL)
Voice VLAN No
GARP VLAN Registration Protocol (GVRP) Yes
Layer 3 Features
Virtual Router Redundancy Protocol (VRRP) Yes
IPv6 Tunneling Yes
Layer 3 Routing
Static Route Yes
Policy-based Route Yes
Routing Information Protocol (RIP) Yes (v1/v2)
Routing Information Protocol Next Generation (RIPng) Yes
Open Shortest Path First (OSPF) Yes (v1/v2/v3)
Border Gateway Protocol (BGP) Yes
Layer 3 Multicasting
Protocol Information Multicast - Dense Mode (PIM-DM) Yes
Protocol Information Multicast - Sparse Mode (PIM-SM) Yes
PIM Sparse-Dense Mode No
Distance-Vector Multicast Routing Protocol (DVMRP) v3 No
Internet Group Management Protocol (IGMP) Yes (v1/v2/v3)
Multi-Protocol Label Switching (MPLS)
VPN Routing and Forwarding (VRF) Yes* (Enhanced I/O module or 7200-ASE3)
MPLS L3 VPN (MPLS / BGP VPN) Yes* (With 7200-ASE3)
MPLS L2 VPN (VPWS / VPLS) Yes* (With 7200-ASE3)
Quality of Service (QoS)
Strict Priority Yes
Weighted Round Robin (WRR) Yes
Strict + WRR Yes
Bandwidth Control (min. granularity) Yes (64kbps)
Time-Based QoS Yes
Access Control List (ACL)
Access Control List Yes (Ingress / VLAN-Based)
(Egress ACL with Enhanced I/O Module)
Time-based ACL Yes
Security
Secure Shell (SSH) Yes (v1.5/v2)
Secure Sockets Layer (SSL) No
Port Security (Entries Per Port) Yes (16)
Traffic Segmentation Yes (Private VLAN)
IP-MAC-Port Binding (IMPB) Yes (ARP Inspection, IP Source Guard,
DHCP Snooping)
D-Link Safeguard Engine Yes (CPP)
Authentication, Authorization & Accounting (AAA)
802.1X Access Control Yes
Web-based Access Control (WAC) No
MAC-based Access Control (MAC) No
Microsoft Network Access Protection (NAP) Yes*
Guest VLAN Yes
Dynamic VLAN Assignment Yes
RADIUS & TACACS+ Authentication for Management Access Yes
Management
Web GUI, CLI & SNMP Yes*
Remote Monitoring (RMON) Yes (v1)
sFlow Yes*
Link Layer Discovery Protocol (LLDP) Yes
Operations, Administration & Management (OAM)
802.3ah Ethernet Link OAM No
802.1ag Connectivity Fault Management (CFM) No
Certification
IPv6 Ready Logo Yes (Phase II)
* Available in Future Firmware Upgrade
