SWITCHES
DGS-1210 Series
Model
DGS-1210-10P
DGS-1210-16
DGS-1210-24
DGS-1210-48
LAN Interface
IEEE 802.3; IEEE 802.3u; IEEE 802.3z; IEEE 802.3ab;
IEEE 802.3af (DGS-1210-10P); Pre-Standard IEEE 802.3at (DGS-1210-10P)
Port Interface
10BASE-T/100BASE-TX/
1000BASE-T Port (RJ-45)
8 (PoE)
12
20
44
Combo 1000BASE-T/SFP Port
2
4
4
4
General Features
Switching Capacity
20Gbps
32Gbps
48Gbps
96Gbps
Maximum Forwarding Rate
14.88Mpps
23.8Mpps
35.7Mpps
71.4Mpps
Forwarding Mode
Store and Forward
Packet Buffer Memory
512KBytes
1MBytes
DDR2 for CPU
64MBytes
Flash Memory
16MBytes
Mean Time Before Failure
(MTBF)
202,249 hours
799,491 hours
410,948 hours
322,402 hours
L2 Features
MAC Address: 8K Entries Per Device, Static MAC Address: 256 Entries;
Flow Control: IEEE 802.3x Flow Control, Head-of-Line (HoL) Blocking Prevention;
IGMP Snooping v1/v2: 256 Groups, Static Multicast Address: 64, IGMP Per VLAN;
Spanning Tree Protocol (STP): 802.1D STP, 802.1w Rapid STP; Loopback Detection;
802.3ad Link Aggregation: Max. 5 Groups Per Device, 8 Ports Per Group (DGS-1210-10P);
Max. 8 Groups Per Device, 8 Ports Per Group (DGS-1210-16/24/48);
Port Mirroring: One-to-One, Many-to-One, Mirroring for Tx/Rx/Both;
Cable Diagnostics; Configurable Auto MDI/MDIX; Multicast Filtering*
Virtual LAN (VLAN)
802.1Q Tagged VLAN; VLAN Group: Max. 256 Static VLAN Groups, Max. 4094 VIDs;
Management VLAN; Asymmetric VLAN; Auto Voice VLAN: Max. 10 User Defined OUI, Max. 8 Default OUI
Quality of Service (QoS)
802.1p Quality of Service; 4 Queues Per Port; Queue Handling: Strict, Weighted Round Robin (WRR);
CoS based on: 802.1p Priority Queues, DSCP;
Bandwidth Control: Port-based (Ingress/Egress, Min. Granularity 64kbps)
Access Control List (ACL)
Max. 50 Profiles; Max. 240 Rules Shared by Profiles; ACL Actions: Permit, Deny;
ACL based on: MAC Address, IPv4 Address (ICMP/IGMP/TCP/UDP), VLAN ID, 802.1p Priority, DSCP
Security
802.1X; Port Security: Max. 64 MAC Addresses Per Port; Broadcast/Multicast/Unicast Storm Control;
Static MAC; D-Link Safeguard Engine; DHCP Server Screening*;
ARP Spoofing Prevention*: Max. 64 Entries; Secure Sockets Layer* (SSL) v1/v2/v3 (IPv4)
Management
Web-based GUI; Compact CLI through Telnet; Telnet Server; TFTP Client;
Simple Network Management Protocol (SNMP) v1/v2c/v3*; SNMP Trap;
Trap for SmartConsole Utility; System Log: Max. 500 Log Entries, IPv4 Log Server;
BootP/DHCP Client; Simple Network Time Protocol (SNTP)
Power Savings
By Link Status and Cable Length Detection
Management Information Base (MIB)
MIB-II (RFC1213); Bridge (RFC1493); SNMPv2 (RFC1907); Trap Convention (RFC1215);
Interface Group (RFC2233); D-Link Private MIB
Standard Compliance
UDP (RFC768); IP (RFC791); ICMP (RFC792); TCP (RFC793); ARP (RFC826);
Telnet Server (RFC854, 855, 858); Telnet Binary Transmission (RFC856);
Congestion Control in TCP/IP Network (RFC896); Reverse Address Resolution Protocol (RFC903);
BootP Client (RFC951); MIB (RFC1155); SNMPv1 (RFC1157); Path MTU Discovery (RFC1191);
Concise MIB Definition (RFC1212); MIB-II, IF (RGC1213); Traps for Use with SNMP (RFC1215);
Standard MIB (RFC1239); TFTP (RFC1350); Bridge MIB (RFC1493); CIDR (RFC1519);
HTTP/1.0 (RFC1945); DHCP (RFC2131); DHCP Options and BootP Vendor Extensions (RFC2132);
RADIUS Authentication (RFC2138); Interface MIB (RFC2233); 802.1p (RFC2647);
Structure of Management Information Version 2 (SMIv2) (RFC2578); SNMP (RFC3416, 3417)
Physical &
Environment
Dimension (W x D x H)
13-inch, 1U Desktop
330 x 180 x 44mm
19-inch, 1U Rack-Mount;
440 x 210 x 44mm
19-inch, 1U Rack-Mount;
440 x 250 x 44mm
Weight
1.84kg
2.87kg
2.97kg
4.04kg
Power Input
AC Input: 100-240 VAC, 50/60Hz; Internal Universal Power Supply
Max. Power Consumption
PoE On: 109.3W
PoE Off: 14.45W
17.4W
24.1W
59.1W
Standby Power Consumption
7W/110V
7.8W/240V
4.9W/110V;
5W/240V
6W/110V;
6.2W/240W
19.2W/110V;
20.1W/240V
Power over Ethernet
All Ports are Selective at
15.4W / 30W
Power Budget: 78W
Time-based PoE
-
Operation Temperature
0 to 40 °C
Storage Temperature
-10 to 70 °C
Operation Humidity
10% to 95% RH
Storage Humidity
5% to 95% RH
Acoustic
0dB
46.2 dB
Fan
Fanless
Smart Fan x 2
Reset Button
One Reset Button
Certification
EMI-EMC Compliance
FCC Class A; CE Class A; IC Report Class A; C-Tick Class A; VCCI Class A
Safety Compliance
cUL; LVD
* Available in Future Firmware Upgrade
Gigabit Ethernet Web Smart Switches
