19
DES-3200 Series
Model DES-3200-10 DES-3200-18 DES-3200-28 DES-3200-28F
LAN Interface IEEE 802.3; IEEE 802.3u; IEEE 802.3z; IEEE 802.3ab
Port Interface
10BASE-T/100BASE-TX
Port (RJ-45)
8 16 24 -
100BASE-X SFP Port - - - 24
Combo 1000BASE-T/SFP Port 2 4
Stackability Virtual Stack D-Link Single IP Management (SIM); Virtual Stack up to 32 Devices
General
Features
Switching Capacity 5.6Gbps 7.2Gbps 12.8Gbps
Maximum Forwarding Rate 4.2Mpps 5.4Mpps 9.5Mpps
Forwarding Mode Store and Forward
Packet Buffer Memory 384KBytes
DDRI SDRAM for CPU 128MBytes
Flash Memory 16MBytes
Mean Time Before Failure
(MTBF)
873,750 hours 743,115 hours 639,525 hours 447,268 hours
Console Port Female RS-232 DB-9 Console Port for Out-of-Band Configuration
L2 Features
MAC Address Table: 8K; Jumbo Frame: Max. 2048Bytes;
Spanning Tree Protocol: 802.1D-2004 Edition STP, 802.1w Rapid STP, 802.1s Multiple STP,
BPDU Filtering, Root Restriction; L2 Protocol Tunneling; Loopback Detection (LBD);
802.3ad Link Aggregation: Max. 5 Groups (DES-3200-10), Max. 9 Groups (DES-3200-18),
Max. 14 Groups (DES-3200-28/28F), Max. 8 Ports Per Group;
Port Mirroring: 1 Mirroring Group, One-to-One, Many-to-One, Flow-based (ACL) Mirroring;
Flow Control: IEEE 802.3x Flow Control, Head-of-Line (HoL) Blocking Prevention;
Ethernet-Ring Protection Switching (E-RPS)*
L2 Multicast
IGMP Snooping v1/v2, v3 Awareness: 1K Groups, Port-based IGMP Snooping Fast Leave;
Limited IP Multicasting: Max. 24 IGMP Filtering Profiles, 128 Groups Per Profile
MLD Snooping v1/v2, v2 Awareness: 1K Groups; IGMP Authentication
L3 Features Gratuitous ARP
Virtual VLAN (VLAN)
802.1Q Tagged VLAN; 802.1v Protocol VLAN; VLAN Group: Max. 4K VLAN; Port-based VLAN;
MAC-based VLAN; GARP VLAN Registration Protocol (GVRP): Max. 255 Dynamic VLAN;
VLAN Trunking; Asymmetric VLAN; ISM VLAN; VLAN Translation
Double VLAN (Q-in-Q): Port-based Q-in-Q, Selective Q-in-Q
Quality of Service (QoS)
802.1p, 4 Queues Per Port; Queue Handling: Strict Priority, Weighted Round Robin (WRR);
CoS based on: Switch Port, VLAN ID, 802.1p Priority Queues, MAC Address, Ether Type,
IP Address, TOS, DSCP, Protocol Type, TCP/UDP Port, User-Defined Packet Content
Actions for Flows: Remark 802.1p Priority Tag; Time-based QoS;
Bandwidth Control: Port-based (Ingress/Egress, Min. Granularity 62.5kbps),
Flow-based (Ingress, Min. Granularity 62.5kbps)
Access Control List (ACL)
Max. 512 Access Rules; Time-based ACL; ACL Statistics; CPU Interface Filtering;
ACL based on: 802.1p Priority, VLAN ID, MAC Address, Ether Type, IP Address, DSCP,
Protocol Type, TCP/UDP Port Number, User-Defined Packet Content, Switch Port
Security
Secure Shell (SSH) v2; Secure Sockets Layer (SSL) v1/v2/v3;
Broadcast/Multicast/Unicast Storm Control; Traffic Segmentation; D-Link Safeguard Engine;
IP-MAC-Port Binding (IMPB): IP Packet Inspection, ARP Packet Inspection, DHCP Snooping,
500 Address Binding Entries Per Device; Port Security: Max. 64 MAC Addresses Per Port;
DoS Attack Prevention; ARP Spoofing Prevention*; BPDU Attack Protection*
Authentication, Authorization & Accounting
(AAA) 802.1X: Port-based Access Control, Host-based Access Control; Two-Level User Account;
Guest VLAN; RADIUS & TACACS+ Authentication for Switch Access; RADIUS Accounting
Management
Web-based GUI (IPv4/IPv6); Command Line Interface (CLI); Telnet Server/Client (IPv4/IPv6);
TFTP Client (IPv4/IPv6); XModem; ZModem; System Log; Dual Image; CPU Monitoring;
Simple Network Management Protocol (SNMP) v1/v2c/v3: SNMP over IPv6; SNMP Traps;
Remote Monitoring (RMON) v1: 1, 2, 3, 9 Groups; RMON v2: ProbeConfig Group; BootP/DHCP Client;
DHCP Auto-Configuration; DHCP Relay; DHCP Relay Option 82; Simple Network Time Protocol (SNTP);
Link Layer Discovery Protocol (LLDP); Password Encryption; Simple Mail Transfer Protocol (SMTP);
Debug Command; Network Load Balancing (NLB)*; IPv6 Management
Operations, Administration & Management
(OAM) Loopback Diagnostics*; Cable Diagnostics*; 802.3ah Link OAM;
802.1ag Connectivity Fault Management (CFM)*
Management Information Base (MIB)
MIB-II (RFC1213); Bridge (RFC1409); SNMPv2 (RFC1907); RMON (RFC1757, 2819);
RMONv2 (RFC2021); Ether-Like (RFC1643, 2358, 2665); 802.1p (RFC2674); IF (RFC2233, 2866);
RADIUS Authentication Client (RFC2618); RADIUS Accounting Client (RFC2620);
Ping & Traceroute (RFC2925); D-Link Private MIB
Physical &
Environment
Dimension (W x D x H) 9-inch, 1U Desktop; 228.5 x 180 x 44mm 19-inch, 1U Rack-Mount; 441 x 207 x 44mm
Power Input AC Input: 100-240 VAC, 50/60Hz; Internal Universal Power Supply
Power Consumption 12.7W 13.2W 18.4W 46.7W
Operation Temperature 0 to 40 °C
Storage Temperature -40 to 70 °C
Operation Humidity 5% to 95% Non-Condensing
Fan Fanless 1 DC Fan
Certification
EMI-EMC Compliance FCC Class A; CE Class A; VCCI Class A; IC
Safety Compliance UL/cUL; CB
Fast Ethernet Metro Ethernet Edge Switches SWITCHES
