pTZ Dome network cameras
Model DCS-6815
ieee standard Wired 802.3, 802.3u
Wired Network port interface 10/100BASE-TX
camera
specification
image sensor 1/4” Exview CCD
lens auto iris
Focal length 3.4~61.2mm
F-number F1.4~F3.0
Minimum Illumination 0.1 Lux (Color); 0.01 Lux (B/W)
Angle of View (Horizontal) 60.8° ~ 3.6°
pan range 360°
Tilt range -10° to 190°
preset point 256
auto cruise Yes
Manual Speed 0° to 90° per second
Pan/Tilt Preset Accuracy 0.225°
Pan/Tilt Preset Speed 5° to 400°
Digital Zoom 12x
Optical Zoom 18x
Day & night ir cut removable Filter
video
Management
video Format MPEG-4 / MJPEG
Video Bit Rate Up to 3Mbps
Max. Video Resolution 720 x 480 (NTSC)
720 x 576 (PAL)
Frame Rate (fps) 30 (NTSC); 25 (PAL)
automatic Focus Yes
Automatic Gain Control Yes
Automatic White Balance Yes
Electronic Shutter (Seconds) 1/1 ~ 1/10,000
Configurable Privacy Mask 16 Zones
auto Flip Yes
Monitor Output BNC
event
Management
Motion Detection Yes
event Triggered recording Yes
email alarm notification Yes
Pre/Post Alarm Buffer Yes
I/O Connector Digital Input / Digital Output
(DI/DO) 8 / 1
Outdoor usage IP66 Standard, Built-in Heater and Fan
physical and
environment
Dimension (Diameter x
Height) 172 x 302.5 mm; 190 x 302.5mm (with sunshield)
Weight 6kg
power input via external power adapter
Max. Power Consumption 65W (with heater)
Operating Temperature -40 to 50°C
storage Temperature -20 to 70°C
Humidity 20% to 80% Non-Condensing
certification FCC, CE, C-Tick, RoHS
ip surveillance pTZ Dome network cameras 81
