SWITCHES
Gigabit Ethernet Layer 3 Chassis Switches
* Available in Future Firmware Upgrade
DES-7200 Series
Model
DES-7206-BASE
DES-7210-BASE
LAN Standard
IEEE 802.3; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3z; IEEE 802.3ae; IEEE 802.3af
General
Features
Max. Switching Capacity
192Gbps (with 2 Control Modules)
384Gbps (With 2 Control Modules)
Passive Backplane Capacity
0.8TBytes
1.6TBytes
Maximum Forwarding Rate
142Mpps (with 2 Control Modules)
286Mpps (with 2 Control Modules)
Packet Buffer Memory
2MBytes
SDRAM for CPU
256MBytes (With 7200-CM1/7200-CM2) / 512MBytes (With 7200-CM3/7200-CM4) - Expandable to 1GBytes
Flash Memory
32MBytes (With 7200-CM1/7200-CM2) / 512MBytes (With 7200-CM3/7200-CM4)
Console Port
RJ-45 Ethernet-based; Out-of-Band Configuration
Extension Flash Storage
Media
Type-A Female USB Port
Base Unit
Expansion Module Slot
Total 6 Slots: 2 for Control Modules + 4 for Port Modules
Total 10 Slots: 2 for Control Modules + 8 for Port Modules
Max. 10BASE-T/100BASE-TX/
1000BASE-T Port (RJ-45)
192
384
Max. 10BASE-T/100BASE-TX/
1000BASE-T PoE Port (RJ-45)
192
384
Max. SFP Port
96
192
Max. 10GE XFP Slot
16
32
Fan Tray
Yes (Built-in); 7206-FAN for DES-7206-BASE
Yes (Built-in); 7210-FAN for DES-7210-BASE
Dust Filter
Yes (Built-in)
Power Supply
No (Need to Select the Suitable Power Supply Module)
Control
Module
Console Module Slot
2
CPU & Management Module
7200-CM1
7200-CM3
CPU Module with 96G Switching Capacity CPU
Module with 96G Switching Capacity &
Support Advanced Service Engine (ASE)
7200-CM2
7200-CM4
CPU Module with 192G Switching Capacity
CPU Module with 192G Switching Capacity &
Support Advanced Service Engine (ASE)
Port Module
Standard Module
7200-24
7200-24G
7200-24P
7200-48
7200-48P
7200-2XG
7200-4XG
12-Port 10/100/1000BASE-T; 12-Port Combo 110/100/1000BASE-T or SFP
12-Port SFP; 12-Port Combo 10/100/1000BASE-T or SFP
12-Port 10/100/1000BASE-T PoE; 12-Port Combo 10/100/1000BASE-T PoE or SFP
44-Port 10/100/1000BASE-T; 4-Port Combo 10/100/1000BASE-T or SFP
44-Port 10/100/1000BASE-T PoE; 4-Port Combo 10/100/1000BASE-T PoE or SFP
2-Port 10-Gigabit XFP
4-Port 10-Gigabit XFP
Enhanced I/O Module
7200-24G2XGE
7200-24GE
7200-48E
12-Port SFP; 12-Port Combo 10/100/1000BASE-T or SFP; 2-Port XFP
24-Port SFP
44-Port 10/100/1000BASE-T; 4-Port Combo 10/100/1000BASE-T or SFP
Advanced Service Engine (ASE) Module
(Require 7200-CM3 or 7200-CM4)
7200-ASE2
7200-ASE3
ASE for IPFIX; Support 128K IPFIX Entries; 6Gbps Throughput
ASE for MPLS; Support 192K Shared Table for Routing and L3 Forwarding Entries; 10Gbps Throughput
Power Supply Module
7200-1200AC
7200-1200DC
7200-2000AC
Power Output: 1,200W; AC Input: 90~264VAC, 40~60Hz
Power Output: 1,200W; DC Input: -36~-72VDC
Power Output: 1,200W@90~176VAC, 2,000W@176~264VAC; AC Input: 90Vac~264VAC, 40~60Hz
RAM Module
7200-512RAM
512MB Extension RAM Module for 7200-CM3/7200-CM4; Support Better Performance when the Network
Requires More Than 128K Routes or MPLS Applications
Fan Module
7206-FAN
Fan Tray for DES-7206-BASE, 6 DC Fans
7210-FAN
Fan Tray for DES-7210-BASE, 6 DC Fans
L2 Features
MAC Address: 16K Per Standard I/O Card, 32K Per Enhanced I/O Card; Jumbo Frame: Max. 9,216Bytes;
Address Resolution Protocol (ARP): Static ARP, Configurable ARP Aging Time;
IGMP Snooping: 1K Groups, IGMP Proxy; Port Mirroring: One-to-One, Multi-to-One, Tx/Rx/Both Port Mirroring;
Spanning Tree (STP): 802.1D STP, 802.1w Rapid STP, 802.1s Multiple STP;
Rapid Ether Ring Protection (RERP): Max. 16 Domains, Recovering L2 Traffic in 500ms;
802.3ad Link Aggregation: 128 Trunk Groups, 8 Ports Per Group; Head of Line Blocking Prevention
Virtual LAN (VLAN)
802.1Q Tagged VLAN, 802.1v Protocol VLAN, VLAN Group: 4K; Port-based VLAN; Super VLAN; Private VLAN;
Double VLAN: Port-based Q-in-Q, Selective Q-in-Q
L3 Features
Max. 2K IP Interface; Secondary IP; Virtual Router Redundancy Protocol (VRRP);
IPv6 Tunneling: Manual Tunnel, ISATAP, 6to4; IPv6 Ready Phase 2
L3 Routing
Routing Entries: 12K, 192K (With 7200-ASE3); Static Routes: Max. 1K; Policy Based Route;
Routing Information Protocol (RIP) v1/v2; RIPng (IPv6)*; Multi Path Route: ECMP/WCMP; BGP+ v4 (IPv6);
Open Shortest Path First (OSPF) v2/v3 (IPv6): Stub/NSSA Area; Border Gateway Protocol (BGP) v4
L3 Multicasting
Protocol Independent Protocol-Dense Mode (PIM-DM); PIM-DMv6*;
Protocol Independent Protocol-Sparse Mode (PIM-SM); PIM-SMv6*;
Protocol Independent Protocol-Source Specific Mode (PIM-SSM); PIM-SSMv6*; PIM Snooping
Internet Group Management Protocol (IGMP) v1/v2/v3
Quality of Service
802.1p Class of Service (CoS); 8 Queues;
Queue Handling: Strict, Weighted Round Robin (WRR), Strict + WRR;
CoS based on: VLAN ID, 802.1p Priority, MAC Address
Multi Protocol Label Switching (MPLS) &
Virtual Private LAN Service (VPLS)
Virtual Routing & Forwarding (VRF) (Require Enhanced I/O module or 7200-ASE3); VPLS* (Require 7200-ASE4);
MPLS Label Management (Require 7200-ASE3); Label Distribution Protocol (LDP) (Require 7200-ASE3);
MPLS L3 VPN (Require 7200-ASE3); Virtual Private Wire Service (VPWS)* (Require 7200-ASE3)
IP Flow Information Export (IPFIX)
Require 7200-ASE2
Security
CPU Protection Policy (CPP); Secure Shell (SSH) v1.5/v2; Port Security: Max. 16 Max Addresses Per Port;
Global MAC-IP Binding; Defeat IP Scan; IP-MAC-Port Binding
Authentication, Authorization & Accounting
(AAA)
802.1X: Port-based Access Control, MAC-based Access Control, Dynamic VLAN Assignment;
Accounting: Period Accounting, Multiple Accounting; Remote Authentication Dial In User Service (RADIUS)
Management
Command Line Interface (CLI); Telnet Server; TFTP; DHCP Server; DHCP Relay; DHCP Relay Option 82; XModem;
Simple Network Management Protocol (SNMP) v1/v2c/v3; SNMP Trap; System Log;
Remote Monitoring (RMON) v1: 1, 2, 3, 9 Groups; System Status LED; System Alert;
DNS Client; Debug; Network Time Protocol (NTP) / Simple Network Time Protocol (SNTP);
File System: Flash Storage Media, Multiple Firmware, Multiple Configuration
Management Information Base (MIB)
MIB-II (RFC1213); Bridge (RFC1493); SNMPv2 (RFC1901, 1907); SNMP (RFC1157, 2571-2576); RIPv2 (RFC1724)
RMON (RFC1271, 2819); PIM-SSM (RFC3569); IP FDB (RFC2096); IGMPv3 (RFC2933); D-Link Private MIB
Standard Compliance
PIM-SM (RFC2362); VRRP (RFC2338, 2787); DVMRP (RFC1075); DiffServ (RFC2474-2475);
802.1p (RFC2674); IGMPv3 (RFC2933); RADIUS (RFC2138-2139, 2865-2866); Super VLAN (RFC3069);
OSPF (RFC1370, 1587, 1765, 1850, 2328, 2370); DHCP (RFC1542, 2131, 3046); (RFC791);
BGP (RFC1771, 1997, 2439, 2796, 2842, 2918); SNMP (RFC3411-3417); UDP (RFC768); IP (RFC791);
TCP (RFC793); Telnet (RFC854); NTP (RFC1305); TFTP (RFC1350); SNTP (RFC1769)
Physical &
Environment
Dimension (W x D x H)
436.8 x 508 x 647.4 mm
436.8 x 448 x 956 mm
Operation Temperature
0 to 40 °C
Storage Temperature
-40 to 70 °C
Humidity
90% Non-Condensing
Certification
EMI-EMC Compliance
FCC Class A; CE Class A; VCCI Class A
Safety Compliance
cUL; CB
