DES-3800 Series
Model
DES-3828
DES-3828DC
DES-3828P
DES-3852
LAN Standard
IEEE 802.3; IEEE 802.3u; IEEE 802.3z; IEEE 802.3ab; IEEE 802.3af (DES-3828P)
Port
Interface
10BASE-T/100BASE-TX
Port (RJ-45)
24
24 (PoE)
48
10BASE-T/100BASE-TX/
1000BASE-T Port (RJ-45)
2
Combo 1000BASE-T/
SFP Port
2
Stackability
Virtual Stack
D-Link Single IP Management (SIM); Virtual Stack up to 32 Devices
General
Features
Switching Capacity
12.8Gbps
15.7Gbps
Max. Forwarding Rate
9.5Mpps
11.7Mpps
Forwarding Mode
Store and Forward
Packet Buffer Memory
32MBytes
SDRAM for CPU
128MBytes
Flash Memory
PROM 512KBytes x 1; Runtime 16MBytes x 1
Mean Time Before Failure
(MTBF)
123,027 hours
133,105 hours
168,110 hours
102,737 hours
Console Port
Female RS-232 DB-9 Console Port for Out-of-Band Configuration
L2 Features
MAC Address Table: 16K; Flow Control: IEEE 802.3x Flow Control, Head-of-Line (HoL) Blocking Prevention;
IGMP Snooping v1/v2/v3: 256 Groups, Static Multicast Addresses: 64, Host-based IGMP Snooping Fast Leave;
Spanning Tree (STP): 802.1D STP, 802.1w Rapid STP, 802.1s Multiple STP; Per Port / Device BPDU Filtering;
802.3ad Link Aggregation: Max. 32 Groups Per Device, Max. 8 Ports Per Group; MLD Snooping v1/v2;
Port Mirroring: One-to-One, Many-to-One, Flow-based; Jumbo Frame: Up to 9KBytes; Loopback Detection
Virtual LAN
VLAN Group: Max. 4K Static VLAN Group, Max. 4K Dynamic VLAN Group; 802.1Q Tagged VLAN;
GARP VLAN Registration Protocol (GVRP); Double VLAN (Q-in-Q); 802.1v Protocol VLAN
L3 Features
128 Static Routing Entries; 2K Hardware Routing Entries; 4K Hardware L3 Forwarding Entries; 64 IP Interfaces;
Open Shortest Path First (OSPF) v2: OSPF Passive Interface, OSPF Equal Cost Route;
Routing Information Protocol (RIP) v1/v2; Virtual Router Redundancy Protocol (VRRP); ARP Proxy
Multicast
Internet Group Management Protocol (IGMP) v1/v2/v3; Distance Vector Multicast Routing Protocol (DVMRP) v3;
Protocol Independent Multicast-Dense Mode (PIM-DM); Protocol Independent Multicast-Sparse Mode (PIM-SM)
Quality of Service (QoS)
Bandwidth Control: Port-based (Ingress/Egress, Min. Granularity 64kbps),
Flow-based (Ingress, Min. Granularity 64kbps);
802.1p Class of Service; 8 Queues; Queue Handling: Strict, Weighted Round Robin (WRR), Strict + WRR;
CoS based on: Switch Port, MAC Address, TOS, DSCP, IP Address, TCP/UDP Port
Access Control List (ACL)
Max. 800 Access Rules; CPU Interface Filtering;
ACL based on: Port, MAC Address, 802.1p Priority, VLAN ID, DSCP, IPv4/IPv6 Address, Protocol Type,
TCP/UDP Port Number, User Defined Packet Content, IPv6 Traffic Class, IPv6 Flow Label
Security
Secure Shell (SSH) v1.5/v2; Secure Sockets Layer (SSL) v2/v3;
Port Security: Max. 16 MAC Addresses Per Port; Broadcast/Multicast/Unicast Storm Control;
Traffic Segmentation; D-Link Safeguard Engine; D-Link ZoneDefense; DHCP Snooping;
IP-MAC-Port Binding: 500 Address Binding Entries Per Device, ARP Packet Inspection; IP Packet Inspection
Authentication, Authorization &
Accounting (AAA)
802.1X: Port-based Access Control, Host-based Access Control, Dynamic VLAN Assignment;
Web-based Access Control (WAC): Port-based Access Control, Dynamic VLAN Assignment;
MAC-based Access Control (MAC): Port-based Access Control, Dynamic VLAN Assignment;
Microsoft Network Access Protection (NAP); Guest VLAN; RADIUS Accounting;
RADIUS and TACACS+ Authentication for Switch Access; Three-Level User Account
Management
Web-based GUI; Command Line Interface (CLI); Telnet Server/Client; TFTP Client; BootP/DHCP Client;
DHCP Auto-Configuration; DHCP Server; System Log; Simple Network Time Protocol (SNTP); CPU Monitoring;
Simple Network Management Protocol (SNMP) v1/v2c/v3; SNMP Trap; DHCP Relay Option 82; Dual Image;
Remote Monitoring (RMON) v1: 1, 2, 3, 9 Groups; RMON v2: ProbeConfig Group; Dual Configuration
Management Information Base (MIB)
MIB-II (RFC1213); Bridge (RFC1493); SNMPv2 (RFC1907); RMON (RFC1757, 2819);
Ether-Like (RFC1643, 2358, 2665); 802.1p (RFC2674); Bridge (RFC4363); IF (RFC2233, 2863);
RADIUS Authentication Client (RFC2618); RADIUS Accounting Client (RFC2620);
RIPv2 (RFC1724); OSPFv2 (RFC1850); IP Forwarding Table (RFC2096); VRRP (RFC2787);
IPv4 Multicast Routing (RFC2932); PIM for IPv4 (RFC2934); D-Link Private MIB
Physical &
Environment
Dimension (W x D x H)
19-inch, 1U Rack-Mount
441 x 310 x 44mm
19-inch, 1U Rack-Mount
441 x 369 x 44mm
19-inch, 1U Rack-Mount
441 x 310 x 44mm
Weight
4.24kg
6.02kg
4.23kg
Power Input
AC Input: 100-240VAC,
50/60Hz; Internal
Universal Power Supply
DC 60W, 48VDC
Internal Universal
Power Supply
AC Input: 90-264VAC,
50/60Hz; Internal
Universal Power Supply
AC Input: 100-240VAC,
50/60Hz; Internal
Universal Power Supply
Max. Power Consumption
36.2W
32.7W
507.2W
47W
Power over Ethernet
-
Power Budget: 370W;
Per Port: 1-16.8W
(Default:15.4W)
Time-based PoE
-
Redundant Power Supply
DPS-200
-
DPS-600
DPS-200
Operation Temperature
0 to 40 °C
Storage Temperature
-40 to 70 °C
Humidity
5% to 95% Non-Condensing
Acoustic
< 51 dB
< 52 dB
< 51 dB
< 53 dB
Certification
EMI-EMC Compliance
FCC Class A; CE; C-Tick
Safety Compliance
CSA International; CB
SWITCHES
Fast Ethernet xStack Layer 3 Core Switches
