Fixed network cameras
Model DCS-3110 DCS-3411 DCS-3415
ieee standard Wired 802.3, 802.3u, 802.3af
Wired Network
port interface 10/100BASE-TX
power over ethernet Yes
camera
specification
image sensor
1/4” 1.3 Megapixel Progressive Color
CMOS 1/4” CMOS 1/4” Sony Progressive Scan CCD
lens vari-Focal, Dc-iris
CS Mount
CS Mount Fixed
Focal length 4.5 ~ 10mm 6mm 4.1 ~ 73.8mm
F-number F1.6 F1.8 F1.4 (Wide); F3.0 (Tele)
Minimum Illumination 1.5 Lux
0.5 Lux (typical)
0 Lux (10m with IR Lens)
1.61 Lux (typical)
0.38 Lux (with ICR On)
Angle of View (Horizontal) 80.5°~37° 41° 48° ~ 2.8°
Angle of View (Vertical) 60° ~ 28° 31° -
Digital Zoom 4x 16x 4x
Optical Zoom - - 18x
Day & night ir cut removable Filter
video
Management
video Format MPEG-4 / MJPEG H.264 / MPEG-4 / MJPEG MPEG-4 / MJPEG
Dual stream Yes - Yes
Multi-Profile - Yes -
Video Bit Rate 20kbps ~ 4Mbps 64kbps ~ 2Mbps 20kbps ~ 4Mbps
Max. Video Resolution 1280 x 1024 (MJPEG)
640 x 480 (MPEG-4)
704 x 480 (NTSC)
704 x 576 (PAL)
640 x 480
Frame Rate (fps) 8 (MJPEG); 30 (MPEG-4) 30 (NTSC); 25 (PAL) 30
automatic electronic
shutter Yes
Automatic Gain Control Yes
Automatic White Balance Yes
electronic shutter
(Seconds)
1/5~1/15,000
1/60~1/100,000 (NTSC)
1/50~1/110,000 (PAL) 1/2~1/10,000
Flip & Mirror Yes
Mobile Video 3GPP
Monitor Output - BNC -
audio
Management
2-Way Audio Yes
Built-in Microphone Yes
External Microphone
(Line In)
Yes
external speaker
(Line Out) Yes
audio recording Yes
audio codec AAC / GSM-AMR GSM-AMR / ADPCM AAC / GSM-AMR
sampling rate ACC: 16~128kbps
GSM-AMR: 4.75~12.2kbps
GSM-AMR: 12.2kbps
ADPCM: 8kbps
ACC: 16~128kbps
GSM-AMR: 4.75~12.2kbps
audio Frequency 20 ~ 20,000Hz
Audio Mute Hardware & Software software Hardware & Software
event
Management
Motion Detection Yes
event Triggered recording Yes
email alarm notification Yes
Pre/Post Alarm Buffer Yes - Yes
storage
Management
Direct to nas Yes
Direct to card slot Yes
external card slot cF card sD card cF card
I/O Connector
Digital Input / Digital
Output (DI/DO) 1 / 1 2 / 1 1 / 1
RS-485 Interface Yes
Outdoor usage With Outdoor Enclosure
DCS-45/ DCS-50/DCS-60 With Outdoor Enclosure
DCS-60
physical and
environment
Dimension (W x D x H) 80 x 143.8 x 62 mm 78 x 177 x 60 mm 80 x 143.5 x 92.4 mm
Weight 521 grams 577.8 grams 1012 grams
power input Via External Power Adapter or Power over Ethernet (PoE)
Max. Power Consumption 4W 5.484W 5.4W
power over ethernet
(IEEE 802.3af) Class 2/3 1
Operating Temperature 0 to 40°C
storage Temperature -20 to 70°C
Humidity 20% to 80% Non-Condensing
certification FCC; CE; C-Tick Fcc, ce, c-Tick, ic, lvD FCC; CE; C-Tick
1 include power Output for external Devices
