Business Wireless
Unified Switch - DWS-4000 Series
Model
DWS-4026
ieee lAn standard
802.3; 802.3u; 802.3z; 802.3ab; 802.3ae; 802.3af
Port
interface
10/100/1000
BASE-T (RJ-45)
20 (PoE)
Combo
1000BASE-T/SFP
4
10 GE Slot
2
XFP Module
DEM-410X
CX4 Module
DEM-410CX
Physical stack
Via CX4/XFP Module; Duplex Chain/Ring Topology;
Bi-Directional Redundant Stacking Topology;
Up to 40Gbps (Full Duplex); Up to 12 Units Per Stack
General
Features
Switch Capacity
88Gbps
Forwarding Rate
65.47Mpps (Maximum)
Forwarding
Mode
Store and Forward
Buffer Memory
750KBytes
MTBF
185,540 hours
Console Port
Female RS-232 DB-9 Console for Out-of-Band Configuration
WLAN Management
Capability
Max. 64 APs Per Switch; Max. 256 APs Per Cluster;
Max. 2048 Wireless Users (1024 Tunneled, 2048 Non-Tunneled)
roaming
Fast Roaming (Wireless Adapter needs to support too)
Intra-Switch / Inter-Switch Roaming;
Intra-Subnet / Inter-Subnet Roaming; AP-AP-Tunnel
Access Control & Bandwidth
Management
Max. 32 SSID Per AP (16 SSID Per RF Frequency Band);
AP Load Balancing based on the No. of Users or Utilization Per AP
Managed Access Point
DWL-8600AP
AP Management
AP Auto-Discovery; Remote AP Reboot;
AP Monitoring: List Managed AP, Authentication Failed AP,
Rogue AP; Ad-Hoc Clients Monitoring;
Client Monitoring: List Clients Associated with Each Managed AP;
AP Authentication Supporting Local Database and External
RADIUS Server; Centralized RF/Security Policy Management;
Visualized AP Management Tool (Support up to 16 JPG Files);
Unified AP Support (DWL-8600AP): Managed/Standalone Mode
WlAn security
Wireless Intrusion Detection & Prevention System (WIDS);
Rogue AP Mitigation; 64/128-bit WEP Data Encryption;
Rogue and Valid AP Classification based on MAC Address;
WPA Personal/Enterprise; WPA2 Personal/Enterprise;
Wireless Station and AP Monitoring on RF Channel,
MAC Address, SSID, Time; Captive Portal; Station Isolation;
Encryption Type Support: WEP, WPA, Dynamic WEP, TKIP,
AES-CCMP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-MD5,
PEAP-GTC, PEAP-MS-CHAPv2, PEAP-TLS; MAC Authentication
L2 Features
MAC Address Table Size: 8K Entries;
IGMP Snooping: 1K Multicast Groups; MLD Snooping;
802.1D STP, 802.1s Rapid STP, 802.1w Multiple STP;
802.3ad Link Aggregation: Max. 32 Groups,
Max. 8 Ports Per Group; Jumbo Frame: Max. 9KBytes;
802.1ab Link Layer Discovery Protocol (LLDP); LLDP-MED;
Port Mirroring: One-to-One, Many-to-One;
Flow Control: 802.3x in Full Duplex, Back Pressure in
Half Duplex, Head-of-Line Blocking Prevention
Virtual LAN (VLAN)
802.1Q Tagged VLAN; 802.1v Protocol VLAN;
VLAN Groups: Max. 3,965 Entries; Subnet-based VLAN;
GARP VLAN Registration Protocol (GVRP);
MAC-based VLAN; Double VLAN; Voice VLAN
L3 Features
IPv4 Static Route; Routing Table Size: Max. 128 Static Routes;
Floating Static Route; Proxy Address Resolution Protocol (ARP);
Virtual Router Redundancy Protocol (VRRP);
Routing Information Protocol (RIP) v1/v2
Quality of Service (QoS)
802.1p Priority Queues (Max. 8 Queues Per Port); Auto-VoIP;
Minimum Bandwidth Guarantee Per Queue;
Traffic Shaping Per Port; Per-Flow Bandwidth Control;
CoS based on: Switch Port, VLAN, DSCP, TCP/UDP Port, TOS,
Dest/Source MAC Address, Dest/Source IP Address
Access Control List (ACL)
ACL based on: Switch Port, MAC Address, 802.1p Queues, VLAN,
Ether Type, DSCP, IP Address, Protocol Type, TCP/UDP Port
lAn security
RADIUS & TACACS+ Authentication for Management Access;
Secure Shell (SSH) v1/v2; Secure Sockets Layer (SSL) v3;
Transport Layer Security (TLS) v1; MAC Filtering;
Denial of Service Protection; Dynamic ARP Inspection (DAI);
Port Security: 20 MAC Per Port, Port Violation Notification;
802.1X Port-based Access Control and Guest VLAN;
Broadcast Storm Control in Granularity of 1% of Link Speed;
DHCP Snooping; Protected Port; DHCP Filtering
Management Methods
Web-based GUI; Switch Clustering; RADIUS Accounting;
Command Line Interface (CLI); Telnet Client; TFTP Client;
Telnet Server: Max. 5 Sessions; sFlow; BootP/DHCP Client;
DHCP Server; DHCP Relay; Dual Images; Port Description;
Multiple Configuration Files; Dual Image Services;
Simple Network Management Protocol (SNMP) v1/v2c/v3;
Remote Monitoring (RMON) v1;
Simple Network Time Protocol (SNTP); System Log
Physical &
Dimension
19-inch; 1U Rack-Mount; 440 x 389 x 44mm (W x D x H)
Weight
6kg
Power input
Input: 100-240 VAC, 50/60Hz; Internal Universal Power Supply
Max. Power
Consumption
525W (With All PoE Ports in Operation)
Poe
Power Budget: 370A; Per Port: 15.4W
rPs
DPS-600
Temperature
0 to 40 °C (Operation); -10 to 70 °C (Storage)
Humidity
10%~90% (Operation); 5%~90% (Storage) Non-Condensing
EMI-EMC
FCC Class A; CE; VCCI; C-Tick; ICES-003; EN 60601 1-2
safety
UL/cUL; CB
Unified Access Point - DWL-8600AP
Model
DWL-8600AP
ieee Wired standard
802.3; 802.3u; 802.3ab; 802.3af
ieee Wireless standard
802.11a; 802.11b; 802.11g; 802.11n
Data
Transfer
rate
802.11a
54, 48, 36, 24, 18, 12 ,9, 6 Mbps
802.11b
11, 5.5, 2, 1 Mbps
802.11g
54, 48, 36, 24, 18, 12 ,9, 6 Mbps
802.11n
Up to 300 Mbps
Wireless
Frequency
range
802.11a
5.15GHz to 5.35GHz
5.47GHz to 5.825GHz
802.11b/g
2.4GHz to 2.4835GHz
802.11n
2.4GHz to 2.497GHz
4.9GHz to 5.85 GHz
RF Channel
5GHz
US & Canada: 12; Europe: 19;
Japan: 8; China: 5 (Non-Overlapping)
2.4GHz
US: 11; Europe: 13; Japan: 13
radio and
Modulation
Type
DBPSK@1Mbps; DQPSK@2Mbps;
[email protected]/11Mbps
802.11a/g
(OFDM)
BPSK@6/9Mbps; QPSK@12/18Mbps;
16QAM@24/36Mbps;
64QAM@48/54Mbps
802.11n
PSK/CCK, DQPSK, DBPSK, OFDM
Transmit
Output
Power
(Typical)
802.11a
17dBm@6/9/12/18Mbps;
15dBm@24/36Mbps;
14dBm@48Mbps; 13dBm@54Mbps
802.11b
17dBm@1/2/5.5/11Mbps
802.11g
17dBm@6/9/12/18Mbps;
16dBm@24/36Mbps;
15dBm@48Mbps; 14dBm@54Mbps
802.11n
5GHz Band/HT-20: 12 to 17dBm;
5GHz Band/HT-40: 11 to 16dBm;
2.4GHz Band/HT-20: 13 to 17dBm;
2.4GHz Band/HT-40: 12 to 16dBm
receiver
sensitivity
802.11a
-87dBm@6Mbps; -86dBm@9Mbps;
-84dBm@12Mbps; -81dBm@18Mbps;
-77dBm@24Mbps; -75dBm@36Mbps;
-68dBm@48Mbps; -67dBm@54Mbps
802.11b
-92dBm@1Mbps; -90dBm@2Mbps;
[email protected]; -84dBm@11Mbps
802.11g
-87dBm@6Mbps; -87dBm@9Mbps;
-85dBm@12Mbps; -82dBm@18Mbps;
-79dBm@24Mbps; -76dBm@36Mbps;
-71dBm@48Mbps; -70dBm@54Mbps
802.11n
5GHz Band/HT-20: -82 to -64dBm;
5GHz Band/HT-40: -79 to -61dBm;
2.4GHz Band/HT-20: -85 to -67dBm;
2.4GHz Band/HT-40: -82 to -63dBm
Antennas
4 Dual Band Detachable Dipole
Antennas
with Reverse SMA Connectors
Antenna
Gain
6dBi for 5GHz Band; 4dBi for 2.4GHz
Band
ethernet interface
10/100/1000BAse-T Port with
802.3af Power over Ethernet (PoE)
Configuration Operation
Modes
Access Point Only;
Wireless Distribution System (WDS);
Access Point with WDs
security
64/128/152-bit Wired Equivalent
Privacy;
MAC Address Filtering: Local/RADIUS;
Wi-Fi Protected Access (WPA)/WPA2
Extensible Authentication Protocol
(EAP);
WPA/WPA2 Pre-Shared Key (PSK);
Temporal Key Integrity Protocol (TKIP);
Advanced Encryption Standard (AES);
802.1Q SSID Broadcast Enable/Disable;
16 SSID Per Frequency Band;
32 SSID Per AP; 802.11i/WPA2;
RADIUS: Max. 4 External RADIUS
Servers;
Isolated Security for Each SSID;
Station Isolation; IEEE 802.1X
supplicant
Management Methods &
Protocols
Protocols Supported in DWS-4026;
HTTP/HTTPS; SSH; SNMP; Syslog; Telnet
Physical &
Dimension
190.5 x 198.8 x 36.8mm (L x W x H)
Weight
1.02kg
Power
input
Via 48VDC, 0.4A External Power
Adapter
Operating Voltage: 48VDC +/- 10%
for Poe
Power
11W with PoE; 12W with PoE
(Maximum)
Operation
0 to 40 °C
storage
-20 to 65 °C
Operation
Humidity
10% to 90% (Non-Condensing)
storage
Humidity
5% to 95% (Non-Condensing)
Certification
FCC Class B; CE; C-Tick; VCCI; TELEC;
Wi-Fi; ICES-003; EN60601-1-2;
NCC; CSA International
unified Wired/Wireless Access system
