SWITCHES

Gigabit Ethernet xStack Layer 3 Core Switches

* Available in Future Firmware Upgrade

DGS-3600 Series

Model

DGS-3612G

DGS-3627

DGS-3627G

DGS-3650

LAN Standard

IEEE 802.3; IEEE 802.3u; IEEE 802.3z; IEEE 802.3ab; IEEE 802.3ae

Port
Interface

10BASE-T/100BASE-TX/
1000BASE-T Port (RJ-45)

SFP Port

Combo 1000BASE-T/
SFP

10 GE Expansion Slot

XFP Expansion Module

DEM-410X

CX4 Expansion Module

DEM-410CX

Stackability

Virtual Stack

D-Link Single IP Management (SIM); Virtual Stack up to 32 Devices

Physical Stack

Via Optional CX4/XFP Module; Bi-Directional Redundant Stacking Topology;

Duplex Chain / Ring Topology; Bandwidth up to 40Gbps (Full Duplex);

Up to 12 Units Per Stack; Backup Master;

Trunking or Mirroring across Stack

General
Features

Switching Capacity

24Gbps

108Gbps

136Gbps

Max. Forwarding Rate

17.86Mpps

80.36Mpps

101.19Mpps

Forwarding Mode

Store and Forward

Packet Buffer Memory

2MBytes

SDRAM for CPU

256MBytes

Flash Memory

PROM 512KBytes x 1; Runtime 16MBytes x 1

Mean Time Before
Failure

342,645 hours

287,631 hours

289,946 hours

246,838 hours

Console Port

Female RS-232 DB-9 Console Port for Out-of-Band Configuration

L2 Features

MAC Address Table: 16K; Flow Control: IEEE 802.3x Flow Control, Head-of-Line (HoL) Blocking Prevention;
IGMP Snooping v1/v2/v3: 1K Groups, IGMP Snooping Fast Leave, Host-based IGMP Fast Leave*;
MLD Snooping v1: 1K Groups, MLD Snooping Fast Leave; Jumbo Frame: Max. 9,216Bytes;
Spanning Tree (STP): 802.1D STP, 802.1w Rapid STP, 802.1s Multiple STP, Per Port/Device BPDU Filtering, Root Restriction*;
Loopback Detection; 802.3ad Link Aggregation: Max. 32 Groups Per Device, 8 Gigabit Ports or 2 10GE Ports Per Group;
Port Mirroring: One-to-One, Many-to-One, Flow-based Mirroring, RSPAN; L2 Protocol Tunneling

Virtual LAN (VLAN)

VLAN Group: Max. 4K Static VLAN Groups, Max. 255 Dynamic VLAN Groups; 802.1Q Tagged VLAN; 802.1v Protocol VLAN;
GARP VLAN Registration Protocol (GVRP); Double VLAN (Q-in-Q): Port-based Q-in-Q, Selective Q-in-Q;
MAC-based VLAN*; Super VLAN*

L3 Features

256 Interfaces; Virtual Router Redundancy Protocol (VRRP); Ethernet-Ring Protection Switching (E-RPS)*;
IPv6 Tunneling*: Static, ISATAP, GRE, 6to4; IPv6 Ready Phase 1/2; Proxy ARP; Gratuitous ARP

L3 Routing

12K Hardware Routing Entries Shared by IPv4/IPv6: Max. 12K IPv4 Routes, Max. 6K IPv6 Routes;
8K Hardware L3 Forwarding Entries Shared by IPv4/IPv6: Max. 8K IPv4 Entries, Max. 4K IPv6 Entries;
Static Route Entries: 256 for IPv4, 128 for IPv6, ECMP/WCMP; Policy-based Route;
Routing Information Protocol (RIP) v1/v2; RIPng (IPv6)*; Border Gateway Protocol (BGP) v4*
Open Shortest Path First (OSPF) v2/v3 (IPv6): OSPF Passive Interface, Stub/NSSA Area, OSPF Equal Cost Route

Multicasting

1K Hardware Multicast Groups; Internet Group Management Protocol (IGMP) v1/v2/v3
Protocol Independent Protocol-Dense Mode (PIM-DM); Protocol Independent Protocol-Sparse Mode (PIM-SM);
PIM Sparse-Dense Mode; Distance Vector Multicast Routing Protocol (DVMRP) v3

Quality of Service (QoS)

802.1p Class of Service (CoS); 8 Queues; Queue Handling: Strict, Weighted Round Robin (WRR), Strict + WRR;
CoS based on: Switch Port, VLAN ID, 802.1p Priority Queues, MAC Address, IPv4/IPv6 Address, DSCP,
Protocol Type, IPv6 Traffic Class, IPv6 Flow Label, TCP/UDP Port, User-Defined Packet Content
Actions for Flows: Remark 802.1p Priority Tag, Remark TOS/DSCP Tag, Bandwidth Control, Flow Statistics,
Committed Information Rate (CIR): Min. Granularity 1kbps; Time-based QoS
Bandwidth Control: Port-based (Ingress/Egress, Min. Granularity 64kbps), Flow-based (Ingress, Min. Granularity)

Access Control List (ACL)

Max. 1,792 Access Rules; ACL Statistics; Time-based ACL;
ACL based on: 802.1p Priority, VLAN ID, MAC Address, Ether Type, IPv4/IPv6 Address, DSCP, Protocol Type,
TCP/UDP Port Number, IPv6 Traffic Class, IPv6 Flow Label, User-Defined Packet Content

Security

Secure Shell (SSH) v1/v2; Secure Sockets Layer (SSL) v1/v2/v3; Port Security: Max. 16 MAC Addresses Per Port;
Broadcast/Multicast/Unicast Storm Control; Traffic Segmentation; D-Link Safeguard Engine; CPU Interface Filtering;
IP-MAC-Port Binding: ARP Packet Inspection, IP Packet Inspection, DHCP Snooping, DHCPv6 & NDP Snooping*,
Max. 500 Address Binding Entries Per Device;
DHCP Server Screening; ARP Spoofing Prevention*; BPDU Attack Protection*

Authentication, Authorization &
Accounting (AAA)

802.1X: Port-based Access Control, Host-based Access Control, Dynamic VLAN Assignment;
Web-based Access Control (WAC): Port-based Access Control, Host-based Access Control, Dynamic VLAN Assignment;
MAC-based Access Control (MAC): Port-based Access Control, Host-based Access Control, Dynamic VLAN Assignment;
Microsoft Network Access Protection (NAP): 802.1X NAP, DHCP NAP; Guest VLAN;
RADIUS & TACACS+ Authentication for Switch Access; Three-Level User Account

Management

Web-based GUI; Command Line Interface (CLI); Telnet Server; Telnet Client*; TFTP Client; ZModem; System Log;
Simple Network Management Protocol (SNMP) v1/v2c/v3; SNMP Trap; Link Layer Discovery Protocol (LLDP);
Remote Monitoring (RMON) v1: 1, 2, 3, 9 Groups; RMON v2: ProbeConfig Group; DHCP Auto-Configuration; DHCP Relay;
DHCP Relay Option 60/61*/82; DHCP Server; Flash File System; Multiple Images; Multiple Configurations; CPU Monitoring;
Simple Network Time Protocol (SNTP); Internet Control Message Protocol (ICMP) v6; IPv6 Neighbor Discovery (ND);
DHCPv6 Client*; DHCPv6 Relay*; DHCPv6 Server*; Cable Diagnostics*; sFlow; BootP/DHCP Client; Debug Command;
D-Link Unidirectional Link Detection (DULD)*

Management Information Base (MIB)

MIB-II (RFC1213); Bridge (RFC1493); SNMPv2 (RFC1907); SNMP (RFC2571-2576); RMON (RFC1271, 2819);
RMONv2 (RFC2021); Ether-Like (RFC2665); MAU (RFC2668); 802.1p (RFC2674); IF (RFC2233, 2863);
RADIUS Authentication Client (RFC2618); RIPv2 (RFC1724); OSPFv2 (RFC1850); VRRP (RFC2787);
IP Forwarding Table CIDR (RFC2096); IPv4 Multicast Routing (RFC2932); PIM for IPv4 (RFC2934);
RADIUS Accounting Client (RFC2620); IGMP (RFC2933); Ping*; Traceroute*; D-Link Private MIB

Standard Compliance

UDP (RFC768); TFTP (RFC783); IP (RFC791); ICMP (RFC792); TCP (RFC793); ARP (RFC826); Telnet (RFC854);
BootP (RFC951, 1542);; HTTP (RFC2068); VRRP (RFC2338); IPv6 Tunnel (RFC2529, 3053, 3056); RADIUS (RFC2138);
RADIUS Accounting (RFC2139); TACACS (RFC1492); sFlow (RFC3176); DiffServ Expedited Forwarding (RFC2598)

Physical &
Environment

Dimension (W x D x H)

19”, 1U Rack-Mount;

441 x 389 x 44mm

Weight (W/O Modules)

5.0kg

5.5kg

5.7kg

Power Input

AC Input: 100-240 VAC, 50/60Hz; Internal Universal Power Supply

Max. Power
Consumption

43.7W

94.3W

75.6W

137.5W

Redundant Power
Supply

DPS-500

DPS-500 / DPS-500DC

Operation Temperature

0 to 40 °C

Storage Temperature

-40 to 70 °C

Operation Humidity

10% to 90% RH

Storage Humidity

5% to 90% RH

Acoustic

< 51.1 dB

< 51.6 dB

< 51.3 dB

< 48.1 dB

Certification

EMI-EMC Compliance

FCC Class A; CE Class A; C-Tick Class A; VCCI Class A

Safety Compliance

cUL; CB

Metro Ethernet Forum

MEF 9, 14
