50
Outdoor Access Points
Model DWL-2700AP
ieee Wired standard 802.3; 802.3u; 802.3af
ethernet interface 10/100BASE-TX (PoE)
ieee Wireless standard 802.11b; 802.11g
Data Transfer rate
802.11a -
802.11b 11, 5.5, 2, 1 Mbps
802.11g 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n -
Frequency Range 5GHz -
2.4GHz 2.4GHz to 2.4835GHz
RF Channel 5GHz -
2.4GHz United States: 11; Europe: 13; Japan: 13
radio and
Modulation Type
802.11a -
802.11b DSSS, DQPSK, DBPSK, CCK
802.11g OFDM, BPSK, QPSK, 16QAM, 64QAM
802.11n -
Transmitter Output
Power (Typical)
802.11a -
802.11b 23dBm@1~11Mbps
802.11g 23dBm@6~54Mbps
receiver sensitivity
802.11a -
802.11b
-91dBm@1Mbps
-90dBm@2Mbps
[email protected]
-84dBm@11Mbps
802.11g
-85dBm@6Mbps
-84dBm@9Mbps
-82dBm@12Mbps
-80dBm@18Mbps
-77dBm@24Mbps
-73dBm@36Mbps
-69dBm@48Mbps
-68dBm@54Mbps
802.11n (2.4GHz) -
802.11n (5GHz) -
Operation Modes Access Point; WDS; WDS with AP
Antenna
Antenna Gain 5dbi
no. of Antennas 2
Antenna Type
Detachable Dipole Antennas with
RN-P N Type Connectors
Physical &
environment
Dimension (mm) 277.7 x 155 x 45
(L x W x H)
Weight 1.82 kg
Outdoor
installation
IP68 Standard; Diecast Watertight Housing
Built-in Heater with Sensor
Power input Via External Power Adapter
Operating/
storage
Temperature
-40 to 60°C / -40 to 65°C
Operating/
storage
Humidity
10% to 90% Non-Condensing / 5% to 95% Non-Condensing
Certification
EMI-EMC
Compliance FCC; CE; C-Tick
safety
Compliance
CSA
Wi-Fi ® Yes
Business Wireless Outdoor Access Points 56
