Fix Dome network cameras
Model DCS-6110 DCS-6111
ieee standard Wired 802.3, 802.3u, 803.3af
Wired Network port interface 10/100BASE-TX
power over ethernet Yes
camera specification
image sensor 1/4” VGA Progressive CMOS 1/4” WDR VGA CMOS
lens Vari-Focal, Board Mount
Focal length 3.7 ~ 12mm 3.3 ~ 12mm
F-number F1.4~F2.8 F1.4~F2.9
Minimum Illumination 1.5 Lux
Angle of View (Horizontal) 77° ~ 23° ~ 63° ~ 18°
Angle of View (Vertical) 57° ~ 17° 47° ~ 13°
Digital Zoom 4x
Day & night Dual-Band Filter ir cut removable Filter
IR LED (20m)
Video Management
video Format MPEG-4 / MJPEG
Dual stream Yes
Video Bit Rate 20kbps ~ 4Mbps
Max. Video Resolution 640 x 480
Frame Rate (fps) 30
Wide Dynamic Range
(WDR) - Yes
automatic electronic
shutter
Yes
Automatic Gain Control Yes
Automatic White Balance Yes
electronic shutter
(Seconds)
1/5 ~ 1/15,000
Configurable Privacy Mask - 5 Zones
Flip & Mirror Yes
Mobile Video 3GPP
Audio Management
2-Way Audio - Yes
External Microphone
(Line In) - Yes
external speaker
(Line Out)
- Yes
audio recording - Yes
audio codec - AAC / GSM-AMR
sampling rate - ACC: 16~128kbps
GSM-AMR: 4.75~12.2kbps
audio Frequency - 20~20,000Hz
Audio Mute - Hardware & Software
Event Management
Motion Detection Yes
event Triggered recording Yes
email alarm notification Yes
Pre/Post Alarm Buffer Yes
Storage Management Direct to nas Yes
I/O Connector
Digital Input / Digital
Output (DI/DO)
1 / 1
physical and
environment
Dimension (W x D x H) 194 x 180 x 107 mm
Weight 630 grams 650 grams
power input Via External Power Adapter or Power over Ethernet (PoE)
Max. Power Consumption 3.6W 11W
power over ethernet
(IEEE 802.3af) Class 1 Class 3
Operating Temperature 0 to 40°C
storage Temperature -20 to 70°C
Humidity 20% to 80% Non-Condensing
certification Fcc, ce, c-Tick
1 include power Output for external Devices
ip surveillance Fixed Dome network cameras 79
