15 SWITCHES
DGS-3200 Series
Model DGS-3200-10 DGS-3200-24
LAN Standard IEEE 802.3; IEEE 802.3u; IEEE 802.3z; IEEE 802.3ab
Port Interface
10BASE-T/100BASE-TX/
1000BASE-T Port (RJ-45) 8 20
Combo 1000BASE-T/SFP 2 4
Stackability Virtual Stack D-Link Single IP Management (SIM); Virtual Stack up to 32 Devices
General
Features
Switching Capacity 20Gbps 48Gbps
Max. Forwarding Rate 14.88Mpps 35.7Mpps
Forwarding Mode Store and Forward
Packet Buffer Memory 128KBytes 768KBytes
SDRAM for CPU 128MBytes
Flash Memory 16MBytes
Mean Time Before Failure 726,077 hours 502,576 hours
Console Port
Female RS-232 DB-9 Console Port for Out-of-Band Configuration (for DGS-3200-10)
Combo Female RS-232 DB-9 / RJ-45 Console Port for Out-of-Band Configuration (for DGS-3200-24)
L2 Features
MAC Address Table: 8K (DGS-3200-10) 16K (DGS-3200-24); Jumbo Frame: Max. 10,240Bytes;
Flow Control: IEEE 802.3x Flow Control, Head-of-Line (HoL) Blocking Prevention; IGMP Authentication;
IGMP Snooping v1/v2/v3: 256 Groups, Host-based IGMP Snooping Fast Leave, Data Driven Multicast;
MLD Snooping v1/v2: 256 Groups; Port Mirroring: One-to-One, Many-to-One, Flow-based Mirroring
Spanning Tree Protocol (STP): 802.1D-2004 Edition STP, 802.1w Rapid STP, 802.1s Multiple STP,
BPDU Filtering, Root Restriction; Loopback Detection;
802.3ad Link Aggregation: Max. 8 Ports Per Group, Max. 5 Groups Per Device (DGS-3200-10),
Max. 12 Groups Per Device (DGS-3200-24)
Virtual LAN (VLAN) 802.1Q Tagged VLAN; VLAN Group: Max. 4094 VLAN; 802.1v Protocol VLAN; ISM VLAN;
GARP VLAN Registration Protocol (GVRP): Max. 255 Dynamic VLANs; VLAN Trunking; Private VLAN
Quality of Service (QoS)
802.1p Quality of Service; 8 Queues Per Port; Queue Handling: Strict, Weighted Round Robin (WRR);
CoS based on: Switch Port, VLAN ID, 802.1p Priority Queues, MAC Address, IPv4/IPv6 Address, DSCP,
TCP/UDP Port No., Protocol Type, IPv6 Traffic Class, IPv6 Flow Label, User-Defined Packet Content
Bandwidth Control: Port-based (Ingress/Egress, Min. Granularity 64kbps,
Flow-based (Ingress, Min. Granularity 64kbps); MAC-based VLAN; Private VLAN
Access Control List (ACL)
Max. 200 Access Rules; Time-based ACL; CPU Interface Filtering; ACL Statistics;
ACL based on: 802.1p Priority, VLAN ID, MAC Address, IPv4/IPv6 Address, DSCP, Protocol Type,
TCP/UDP Port Number, IPv6 Traffic Class, IPv6 Flow Label, User-Defined Packet Content
Security
Secure Shell (SSH) v2; Secure Sockets Layer (SSL) v1/v2/v3;
Broadcast/Multicast/Unicast Storm Control; Traffic Segmentation; D-Link Safeguard Engine;
IP-MAC-Port Binding: ARP Packet Inspection, IP Packet Inspection, DHCP Snooping,
512 Address Binding Entries Per Device; Port Security: Max. 64 MAC Address Per Port;
Microsoft Network Access Protection (NAP): 802.1X NAP (IPv4/IPv6), DHCP NAP (IPv4);
DHCP Server Screening; DHCP Client Filtering; ARP Spoofing Prevention
Authentication, Authorization & Accounting
(AAA)
802.1X: Port-based Access Control, Host-based Access Control, Dynamic VLAN Assignment;
Web-based Access Control (WAC): Port-based Access Control, Host-based Access Control,
Dynamic VLAN Assignment;
MAC-based Access Control (MAC): Port-based Access Control, Host-based Access Control,
Dynamic VLAN Assignment; Compound Authentication; Guest VLAN;
RADIUS and TACACS+ Authentication for Management Access; RADIUS Accounting
Management
Web-based GUI (IPv4/IPv6); Command Line Interface (CLI); Telnet (IPv4/IPv6);
XModem; ZModem; Simple Network Management Protocol (SNMP) v1/v2c/v3; SNMP Trap;
Remote Monitoring (RMON) v1: 1, 2, 3, 9 Groups; RMON v2: ProbeConfig Group; BootP/DHCP Client;
TFTP Client (IPv4/IPv6); DHCP Auto-Configuration; DHCP Relay; DHCP Relay Option 82;
Simple Network Time Protocol (SNTP); Internet Control Message Protocol (ICMP) v6;
IPv6 Neighbor Discovery; System Log; CPU Monitoring; Dual Image; Dual Configuration
Operations, Administration & Management
(OAM)
Cable Diagnostics
D-Link Green Power Savings Mode: Link Down Status, Cable Length Detection; Compliant with RoHS 6
Management Information Base (MIB)
MIB-II (RFC1213); Bridge (RFC4188); SNMPv2 (RFC1907); RMONv2 (RFC2021); 802.1p (RFC2674);
Ether-Like (RFC1643, 2358, 2665); IF (RFC2233, 2863); Ping & Traceroute (RFC2925);
RADIUS Authentication Client (RFC2618); RADIUS Accounting Client (RFC2620); D-Link Private MIB
Standard Compliance
UDP (RFC768); TFTP (RFC783); IP (RFC791); ICMP (RFC792); TCP (RFC793); ARP (RFC826);
Telnet (RFC854); BootP (RFC951, 1542); HTTP (RFC2068); RADIUS (RFC2138); ICMPv6 (RFC4443);
RADIUS Accounting (RFC2139, 2866); TACACS (RFC1492); SNMPv1 (RFC1157);
SNMPv2c (RFC1901, 1908); SNMPv3 (RFC2570, 2575); 31-Bit Prefixed (RFC3021); IPv6 (RFC2460);
IPv6 Neighbor Discovery (RFC4861); Stateless Address Auto-configuration (RFC4862);
IPv6 Path MTU Discovery (RFC1981); Deprecation of Type 0 Routing Headers in IPv6 (RFC5095)
Physical &
Environment
Dimension (W x D x H) 11-inch, 1U Height;
280 x 180 x 43mm
19-inch, 1U Rack-Mount;
440 x 210 x 44mm
Power Input AC Input: 100-240 VAC, 50/60Hz; Internal Universal Power Supply
Max. Power Consumption 20.9W 41.9W
Redundant Power Supply - DPS-200
Operation Temperature 0 to 40 °C 0 to 50 °C
Storage Temperature -40 to 70 °C
Humidity 5% to 95% Non-Condensing
Fan Fanless 2 Smart Fan (Default Low Speed)
SD Card Reader - Yes
Certification EMI-EMC Compliance FCC; CE; C-Tick; VCCI Class A
Safety Compliance UL; CB Report
Gigabit Ethernet xStack Layer 2 Secure Switches
