Step 13
i
Parts Needed For
i
Right Roof Panel
>6640 Right Roof Panel (1)
Installing the roof panels is best done
with a step ladder. Begin installing
roof panels at the back rightcornerof
the building. Each screw and bolt in
the roof requires a washer.
NOTE
Measure the building diagonally
again and make adjustments to
make sure the building is square.
This will make the roof panels fit
better, and holes will align.
NOTE
if
a
Roof Beef-Up Kit
was
purchased, assemble prior to
attaching the roof panels.
1
Locate all the roof panels by their
numbers and place them on the
ground alongside the building in their
proper positions.
2
Position a
right roof panel
at the
back right corner and fasten to the
gable and roof beams using screws
and bolts and nuts as shown.
Do not
fasten the lower end of the panels to
the side wall angles at this time.
Hint:
Follow the fastener sequence
shown, for proper alignment.
STEP
6641
6529
6529
6640
2
1 •
4
3
■
6
b
8
7
6640
6529
6529
6641
FRONT
6 thru 9
6640 Right Roof Panel
Nut
Washer’
