Assembly
Kev No.
Part
Number
Part
Description
Quantity
in Carton
Check
List
1
3719
Door Handle Brace
2
2
5986
Rear Wall Angle
2
3
6000
Right Gable
2
4
6001
Left Gable
2
5
6015
Side Roof Trim
4
6
10497
Horizontal Door Brace
4
7
9355
Vertical Door Brace
2
8
6403
Door Track Splice
1
9
9156
Corner Panel
4
10
8995
Wall
Panel
8
11
6529
Roof Panel
4
12
6635
Gable Brace
2
13
6640
Right Roof Panel
2
14
6641
Left Roof Panel
2
15
6869
Ridge Cap
2
16
9917
Rear Wall Channel
2
17
10489
Right Door
1
18
10489
Left Door
1
19
8934
Ramp
1
20
8936
Rear Floor Frame
2
21
9923
Side Wall Channel
4
22
9294
Right Roof Beam
4
23
9295
Left Roof Beam
4
24
9298
Side Wall Angle
4
25
9299
Side Floor Frame
4
26
9365
Front Wall Channel
2
27
9366
Door Track
2
28
9367
Front Floor Frame
2
29
9900
Door Jamb
2
30
9372
Front Wall Panel
2
12
