SPECIFICATIONS Speaker system SX-NA54
Main unit CX-NMT50
FM tuner section
Tuning range
Usable sensitivity (IHF)
Antenna terminals
AM tuner section
Tuning range
Usable sensitivity
Antenna
Ampiifier section
Power output
Total harmonic distortion
Inputs
Outputs
87.5 MHz to 108 MHz
13.2 dBf
75 ohms (unbalanced)
530 kHz to 1710 kHz (10 kHz
step)
531 kHz to 1602 kHz (9 kHz step)
350 pV/m
Loop antenna
Front
60 W + 60 W (50 Hz - 20 kHz,
THD less than 1%, 6 ohms)
Rear (Surround)
10 W + 10 W (1 kHz, THD less
than 1%, 16 ohms)
Center
20 W (1 kHz, THD less than 1%,
8 ohms)
0.05 % (50 W, 1 kHz, 6 ohms, DIN
AUDIO)
VIDEO/AUX: 150 mV (adjustable)
MD: 150 mV (adjustable)
MIC 1, MIC 2: 1 mV (lOkohms)
LINE OUT: 200 mV
SUPER WOOFER: 1.9 V
SPEAKERS: accept speakers of
6 ohms or more
SURROUND SPEAKERS:
accept speakers of 16 ohms or
more
CENTER SPEAKER: accept
speakers of 8 ohms or more
PHONES (stereo jack): accepts
headphones of 32 ohms or more
Cabinet type 3 way, bass reflex (magnetic
shielded type)
Speakers Woofer:
160 mm (6% in.) cone type
Tweeter:
80 mm (3V4 in.) cone type
Super tweeter:
20 mm (’®/i6 in.) ceramic type
Impedance 6 ohms
Output sound pressure level 87 dB/W/m
Dimensions (W x H x D)
243 x 304 x 227 mm (9% x 12 x 9
in.)
Weight 3.3 kg (7 lbs 4 oz.)
Specifications and external appearance are subject to change without
notice.
uou SYSTEM
The word “BBE” and the “BBE symbol” are trademarks of BBE
Sound, Inc.
Under license from BBE Sound, Inc.
DOLBY PRO LOGIC
Manufactured under license from Dolby Laboratories Licensing
Corporation.
“DOLBY” and "PRO LOGIC” are trademarks of Dolby Laboratories
Licensing Corporation.
COPYRIGHT
Please check the laws on copyright relating to recordings from
discs, radio or external tape for the country in which the machine
is being used.
Cassette deck section
Track format
Frequency response
Recording system
Heads
4 tracks, 2 channels stereo
Cr02 tape: 50 Hz - 16000 Hz
Normal tape: 50 Hz - 15000 Hz
AC bias
Deck 1: Playback head x 1
Deck 2: Recording/playback/
erase head x 1
Compact disc player section
Laser
D-A converter
Signal-to-noise ratio
Harmonic distortion
Wow and flutter
General
Power requirements
Power consumption
Dimensions of main unit
(W X H x D)
Weight of main unit
Semiconductor laser (^ = 780 nm)
1 bit dual
85 dB (1 kHz, 0 dB)
0.05 % (1 kHz, 0 dB)
Unmeasurable
120 VAC, 60 Hz
120 W
260 X 309 x 346 mm
(10V4X 12V4X 13% in.)
7.5 kg (16 lbs 9 oz.)
