SPECIFICATIONS
Main unit CX-NA71
FM tuner section
Tuning range
Usable sensitivity (IHF)
Antenna terminals
AM tuner section
Tuning range
Usable sensitivity
Antenna
Amplifier section
Power output
Total harmonic distortion
Inputs
Outputs
Cassette deck section
Track format
Frequency response
Signal-to-noise ratio
Recording system
Heads
87.5 MHz to 108 MHz
13.2 dBf ^
75 ohms (unbalanced)
530 kHz lo 1710 kHz (10 kHz
step)
531 kHz to 1602 kHz (9 kHz step)
350 pV/m ,
Loop antenna
100 W + 100 W (50 Hz-20 kHz,
THD less than 1%, 6 ohms)
0.05% (90 W, 1 kHz, 6 ohms, DIN
AUDIO) '
VIDEO/AUX: 210 mV (adjustable)
MD: 210 mV (adjustable)
MIC 1, MIC 2:1.4 mV (10 kohms)
LINE OUT: 200 mV
SUPER WOOFER; 2.4 V
SPEAKERS: accept speakers of
6 ohms or more
SURROUND SPEAKERS:
accept speakers of 16 ohms or
more
PHONES (stereo jack); accepts
headphones of 32 ohms or more
4 tracks, 2 channels stereo
Cr02 tape: 50 Hz - 16000 Hz
Normal tape: 50 Hz - 15000 Hz
60 dB (Dolby B NR ON, Cr02 tape
peak level)
AC bias
Deck 1: Playback head x 1
Deck 2: Recording/playback/
erase head x 1
Compact disc player section
Laser ’
D-A conyerter
Sighal-to-noise ratio
Harmonic distortion
Wow and flutter
General
Power requirements
Power consumption
Dimensions of main unit
( W x H x D )
Weight of main unit
Semiconductor laser (k = 780 nm)
1 bit dual .
90 dB (1 kHz, 0 dB)
0.03 % (1 kHz, 0 dB)
Unmeasurable
120 VAC, 60 Hz
115 W
260 X 309 X 362.5 mm
(10V4
X
12V4X lAVsin.)
8.5 kg (18 lbs 12 oz.)
Speaker svstem SX-NA74 ÍFor NSX-A740. NSX-A74Í
Cabinet type
3 way, bass reflex (magnetic
shielded type) ,
Speakers Woofer:
160 mm (6% in.) cone type
tweeter: .
80 mm (3V4 in.) cone type
Super tweeter: . .
20 mm ('Vie in.) ceramic type
Inipedance , 6 ohms
Output sound pressure level 87dB/W/m
Dimensions (W x H x D) 243
X
304 x 255 mm (9Vs x 12 x
lOVsin.)
Weight 3.8 kg (8 lbs 6 oz.)
Speaker svstem SX-ANA72 (ForNSX-A72l
Cabinet type 4 way, bass reflex with surround
speaker (magnetic shielded type)
Speakers Woofer:
160 mm (6% in.) cone type
Tweeter:,
50 mm (2 in.) cone type
Super tweeter:
20 mm ('Yi6 in.) ceramic type .
Cardioid speaker:
80 mm (3V4 in.) cone type ,
Surround speaker:
80 mm (3V4 in.)
Impedance Front speaker:
6 ohms
Surround speaker:
16 ohms
Output sound pressure level 87 dB/W/m ,
Dimensions (W x H x D) 250
X
310
X
280 mm (9Vs x 12V4
x 11 Vs in.)
Weight 4.5 kg (9 lbs 15 oz.)
Speaker svstem SX-FNA71 ÌForNSX-A71l
Cabinet type 3 way, bass reflex with surround
speaker (magnetic shielded type)
Speakers Woofer:
160 mm (6^8 in.) cone type
Tweeter: ,
80 mm (3V4 in.) cone type
Super tweeter:
20 mm (^Vi6 in.) ceramic type ,
Surround speaker:
80 mm (3V4 in.)
Impedance Front speaker: ,
6 ohms
Surround speaker:
16 ohms ,
Output sound pressure level 87 dBAA//m
Dimensions (W x H x D) 250 X 304 X 288 mm (9Vs x 12 x
11% in.)
Weight 3.6 kg (7 lbs 15 oz.)
25
Specifications and external appearance are subject to change without
notice.
, !
uau SYSTEM , ,
The word “BBE” and the “BBE symbol” are trademarks of BBE
Sound, Inc.
Under license from BBE Sound, Inc.
DOLBY NR
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“DOLBY” and the double-D symbol □□ are trademarks of Dolby
Laboratories Licensing Corporation.
COPYRIGHT
Please check the laws on copyright relating to recordings from
discs, radio or external tapé for the couritry In which the machine
is being used.
-
