PARTS LIST FOR CRAFTSMAN DELUXE 10 INCH TABLE SAW MODEL NO. 113,241691
FIGURE 3 - RIP FENCE ASSEMBLY 62952
Key
No.
Part
Key
No.
Part
No.
Description
No,
Description
1
62942
Handle
10
62529
Lock, Rear Fence
2
62945
Shoe
11
62531
Roller, Rear Fence
3
62775
Indicator
12
62944
Rod, Fence Lock
4
9404336
Screw, Pan Cross Type “T”
13
62533
Spring, Head Alignment
N0.4-40x1/4 ................
{Includes Key #18)
5 . 62941
Head, Fence ..............................
14
STD 551210 ‘Lockwasher, External No. 10
6
423567
Screw. Sems 3/8-16 x 1/2
15
STD611005
'Screw, Hex Head Type “A"
7
62946
Channel, Fence
No 10x1/2
8
STD600805
‘Screw, Pan Cross Type “T”
16
62532
Pad, Alignment
8-32 X 1/2
17 62940
Cam
9
62528
Spring, Fence Lock
18
62943
Nut, Adjustment
