REPAIR PARTS
20 HP. GARDEN TRACTOR -
TRANSAXLE PEERLESS -
MODEL NUMBER 917.254460 AND 917.250040
■ MODEL NUMBER 143-820-016
Ref.
No, Part
No. Part Name
Ref.
No.
Part
No. Part Name
1 770m Case, Transaxie 44 786131 Cap, Bearing
2 778253 Gear, Spur (15 teeth! 45 780165 Washer, Flat
3 778211 Gear, Spur (12 teeth) 47 772098 Cover, Transaxle
4 778240 Gear, Spur (18 teeth) 48 784342 Rod & Fork Assy , Shift
5 778201 Gear. Spur (25 teeth) 49 776274 Shaft, Input
6 778202 Gear, Spur (28 teeth) 50 776313 Shaft, Brake (4 Keyed)
6A 778208 Gear, Spur (31 teeth) 51 790007 Plate, Brake pad
7 778209 Gear, Spur (19 teeth) 52 790006 Pad, Brake
8 778203 Gear, Spur (22 teeth) 53 786026 Pin, Dowel
9 778204 Gear, Spur (25 teeth) 54 792075 Locknut, 5/16-24
to 778239 Gear. Spur (32 teeth) 55 792076 Washer, Flat
11 778207 Gear, Spur (37 teeth) 56 790047 Lever, Brake
11A 778216 Gear. Spur ¡41 teeth) 57 792073 Screw, Flanged hex hd thread-
12 778246 Gear, Bevel (33 teeth) forming, 1/4-20 x 1-1/4
13 784216 Collar, Shift 57A 792085 Screw, Flanged hex hd thread-
14 786123 Sprocket (18 teeth) forming, 1/4-20 x 2-1/4
15 786082 Sprocket (9 teeth) 58 790025 Holder, Brake pad
16 776291 Shaft, Counter (w/9 tooth gear) 59 778197 Pinion, Differentia! bevel
17 778245 Bevel Pinion, Irrput (13 teeth) 59A 778198 Gear, Bevel
18 786121 Spacer, Natural (,3S)/ 340 thick) 60 786019 Pin, Drive
18A 786122 Spacer, Neturai (,276/.268 thick) 61 786027 Block, Drive
19 776275 Shaft. Output (9 teeth) 62 774833 Carrier, Differential (Threaded holes)
20 778247 Gear. Output ¡35 teeth) 62A 774834 Carrier, Differential
21 790043 Disk. Brake 63 778248 Gear, Ring ¡31 teeth)
22 7'&2138 Kev 64 780107 Washer
23 780084 Bearing, Thrust 65 780042 Washer, Thrust
25 788040 Ring, Retaining 66 792018 Ring, Snap
26 780051 Washer. Thrust 67 792020 Screw, Hex hd., 1/4-20 x 2-1/4
27 7B0071 Bearing, Thrust 68 792006 Lockwasher, 1/4"
28 786081 Chain, Roller (No 41 chain, 24 links) 69 774832 Axle ¡12-5/16" long)
29 780072 Washer, Thrust 70 774831 Axle (16-3/16" long)
30 780155 Bearing, Needle 71 792074 Plug, Hex hd , 9/16-18 thread
31 792077 Bail, Steel 72 786067 Spacer
32A 780139 Washer, Thrust 73 786086 Bracket, Brake lever
33 792078 Screw, Set, 3/8-16 x 3/8 76 780153 Washer
34 792079 Spring 77 786144 Sleeve (stepped)
35 792073 Screw, Flanged hex hd thread- 78 780150 Bearing, Needle
forming, 1/4-20 x 1-1/4 79 780152 Bearing, Needle (capped)
35A 792129 Screw, Hex hd threadforming. 80 792001 "0" Ring
5 / 1 6 - 1 8 x 1 - 1 / 4 ' 8 1 786142 Sleeve (stepped)
36 780108 Washer. Thrust 82 788071 Ring, Square cut
37 780119 Bearing, Ball 83 780049 Bearing, Needle (capped)
38 780128 Washer, Thrust 84 786143 Sleeve (stepped)
39 780050 Bearing, Bail 85 780151 Bearing, Needle (capped)
40 792128 Washer, Flat 86 786145 Sleeve (stepped)
41 7m77 "O" Ring 87 788070 Ring, Square cut
42 788042 Seal, Oil 88 780031 Bearing, Needle
43 780166 Washer, Cupped
NOTE: All component dimensbns given in U.S, inches.
1 inch » 25,4 mm.
