REPAIR PARTS
20 H.P. GARDEN TRACTOR - MODEL NUMBER 917.254460 AND 917.250040
CHASSIS AND ENCLOSURES NOTE: All component dimensions given in U S inches
KEY PART DESCRIPTION
NO NO
1 120066X Seat
2 124294X Pan - Seat
3 WS513X Bracket ■ Pivot • Seat
4 10S529X Bolt • Shoulder 5/16 ■ 18
5 124238X Cap ■ Spring
S 73680500 Nut • Lock 5/16 ■ 18
7 73680600 Nut • Lock 3/8 16
8 123784X Fender
9 106202X Reflector Rear
10 105801X Decal
11 17490612 Screw, Hex Washer Thd Roll
3/8-16x3/4
12 19131312 Washer 13/32 x 13/16 x 12 Ga
13 STD523707 ’Bolt. Hex- 3/8-16 X 3/4
14 10551IX Strap - Fender
15 73220400 Nut, Fin. Hex 1/4-20
16 19171912 Washer 17/32 x 1-3/16 x 12 Ga.
17
120684X Washer, Neoprene
18 121246X Bracket, Switch - Seat
19 124181X Compression ■ Spring R H
20 10SS31X Nut, Push
21 WS509X Bracket ■ Fender
22 123934X Scale, Height Indicator
23 106020X Tank Fuel
24 123549X Cap • Fuel
25 123487X Clamp ■ Hose
26 8S42R Line - Fuel
27 106082X Pad ■ Spacer
28 121277X Chassis Assembly
29
123785X Drawbar
30
124118X Panel - Dash L H
31
121794X Cover, Access
32 110828X Panel Dash ■ R H.
33 105525X Bracket ■ Support - Dash
34 123933X Pointer, Height Indicator
35 10546SX Footrest - L H--
36 W5464X Footrest ■ R H.
37 STD533707 ' Bolt- Carr 3/8 16 X 3/4
38 W5466X Pad, Footrest
39 110923X Bracket - Clutch Mower
40 3645J Bushing
41 105S67X Decal-6 Speed 44 "
42 2751R Clip - Insulated
43 110436X
Grommet, Split
48 109015X Bracket ■ Pivot ■ L H
49 W9016X Bracket ■ Pivot • R H
SO 106013X017 Hood
51 12393SX Plug, Hole
52 73680400 Nut - Crownlock t/4-20
54 108067X Pa! ■ Nut
55 WSS28X Grill
56 WS806X Decal - Grill
5 7 Í0S568X Decal - Stripe
'STANDARD HARDWARE-PURCHASE LOCALL Y
1 inch = 25 4 mm
KEY PART DESCRIPTION
NO NO
58 121248X Bushing, Snap
59 121249X Spacer. Split
60 Í21250X Spring. Compression
6 1 W8403X Panel ■ Side
Я H
6 2 Ю84ЮХ Panel Side L H
6 3 126432X Hinge R H
64 126431X Hinge L H
66 W6003X Lens R H
6 7 106004X Lens L H
68 110897X Berel ■ Head light
70 W8512X Bracket
■
Pivot R И
71 Ю8513Х Bracket Pnnt L И
72 4900J Веса/ Clutch Bi.ike
73 W9199X Decal Drive Brit
74 74760612 Bolt Hex 3 S 16 ^ 3/4
75 87103 Stem - Tank Fuei
76 1 W350X Strap Assemhiy Gnil
79 11050600 Washer Loi к Ext Tooth 3/8
80 106813X Decal Strifie Side Panel. L H
81 106814X Decal Stripe Side Panel. R H
82 106974X Decal Caution
83 17490608 Bolt, Hex Washer Thread Rolling 3/8 -
16X1/2
85 1 9 1 3 l 6 t 4 Washer 13 32 x 1 к 14 Ca
86 19060718 Washer 3/16 X 7/16 X 18 Ga.
87 106909X Screw - Special
88 10691OX Washer
89 108402X UClip
90 121251X Strip. Foam
91 72170410 Bolt. Carr. 1/4 - 20 X 1-1/4
92 120068X Knob. Seat
93 121144X
Shoulder Bolt
94 5320R
Clip insulated
95 123976X Nut, Hex Large Flange
96 74641008 Screw - Slid Pan Head #10 - 24 x 1/4
97 73951000 Nut, Keps #10-24
98 4171R Clip. Insulated
99 123825X Console, Shifter
101 126313X Decal, Hood
102 10100800 Washer, Loedt
103 74640806 Screw m X 3/8
104 74780516 Bolt, Hex 5/16 - 18 UNC x 1
105 19112410 Washer 11/32 x 1 1/2x 10 Ga
106 10040500 Washer, Lock
107 120529X Washer, Nylon
108 9151R Grommet
109 120579X Pal Nut
110 750211 Decal, U.S A
