20 HP. GARDEN TRACTOR - MODEL NUMBER 917.254460 AND 917.250040
STEERING ASSEMBLY
REPAIR PARTS
KEY PART DESCRIPTION KEY PART DESCRIPTION
NO NO,
NO NO
? 10581 OX Decal • Cap Steering Wheel 46 73901000 Nut. Lock. Flange 5/8-11
2 1007WL Insert, Steering Wheel 47 17490508 Screw, Hex Washer Thd Rolling
3 73940800 'Nut Top Lock 1/2 - 20UNf 5/16 IB X 1.Q
4 100712K Washer 48 105656X Spindle. L H.
5 121021X Wheel. Steering 49 10S654X Spindle. R H
6 W0711L 'Adapter ■ Steering Wheel 50 121749X Washer 25/32 X 1-1/4 x 16 Ga
7 110709X Column - Steering 51 121334X Rod. Tie
8 120028X Dash 52 STD551131 'Washer. Lock 5/16
9 124557X011 Dash Plate 53 STD541131 'Nut. Hex 5/16-24
10 109816X Nylmer. Snap-In 54 3.366R Bearing
n 17490608 Screw, Нек Washer Thd Rolling 55 124032X Link. Drag
3/8-16 X 1/2 56 STD551137 ‘Washer. L ock 3/8
12 12174BX Washer 25/32 к 1-5/3 к 16 Ga 57 STD541137 'Nut, Hex 3/8-24
13 124041X Shaft, Steering 58 1554.J Bushing. Steering
16 124036X Bracket, Steering 59 17431008 .Screw. Hex No 10-16 x 1/2
17 124037X Gear. Pinion 60 W4757X Cap. Hub, Front
18 17490612 Screw. Hex Washer Thd Rolling 61 2751Я Clip. Fuel Line
3/8-16 X 3/4 62 STD54W37 'Nut, Hex 3/8-16
19 124033X Shaft, Pitman 63 121232X Spindle, Cap
20 12000029 Klip Ring 64 59192 Cap. Valve
21 6266H Bearing, Thrust 65 65139 Stem. Valve
22 124034X Gear, Sector 66 278H Fitting. Grease
24 10S518X Dash. Lower 67 9040H Bearing
25 74180512 Screw, Crown Truss Hd 68 106732X Rim, 6" Front
5/16 18x3/4 63 106222X Tire. Front
26 73680500 Nut. Lock 5/16-18 71 108456X Decal, Instructions. Operating
27 123783X012 Saddle 72 59904 Tube. Tire. Front
28 73680600 Nut. Lock 3/8-16
73 72110622 Bolt. Carriage Hex 3/8-16 x 2 3/4
29 STDS 23120 'Bolt. Hex 5/16-18 X 2 74 121235X Spacer
30 121236X Spacer 75 19131416 Washer 13/32 x 7/8 x 16 Ga
31 10600IX Support Plate. Battery 77 STDS 12507 ‘Screw. Pan Head 1/4-20 x 3/4
32 STD523707 'Bolt, Hex 3/816 x 3/4
78 19091216 Washer 13/32 x 3/4 x 16 Ga
33 57079 Washer
79 73510400 Nut. Keps 1/4 NC
34 124035X Shaft, Support
80 19272016 Washer 27/32 X 1-1/4 x 16 Ga
35 126684X Washer 5/8 x 1/4 x 16 Ga.
82 122819X Screw, Special 3/8 - 16x3/4
36 12S727X Control. Choke
84 19111216 Washer 11/32 x 3/4 x 16 Ga
38 11050600 Washer. Lock, Int /Ext Tooth 3/8 86 STD551125 Lockwasher 1/4
39 72110608 Bolt. Carriage 87 71070410 Screw, Socket Hex 1/4 x 20x 5/8
40 108075X Axle. Front
41 105663X Support. Saddle, Rear
42 74761060 Bolt. Hex 5/8-11 X .3-3/4
43 105664X Support, Saddle. Front
45 110438X Spacer Bearing Front Axle 'STANDARD HARDWARE - PURCHASE LOCALLY
NOTE: All component dimensions given in U S inches
1 inch = 25 4 mm
A в C D E F G
® 2S
F G H J H L
?59 ? *73
Wn t
77
<© 56
^ 038
©28 ©
78
79
® 75
0 ”
Фт
35
82
