Page 1 of 5 – Rev 9/19/2012
OPERATION INSTRUCTIONS
Tactical Security Lock-Box #301
Opening the Tuffy Security Lock-box
1. Using the pushbutton key lock:
Warning: keep clear of the lid when opening it. There is a gas strut which forces
the lid open.
1.1. Locate the key and unlock the pushbutton lock.
1.2. Press the pushbutton while at the same time pulling the lid open using the handle.
2. Using the pushbutton combination lock:
Warning: keep clear of the lid when opening it. There is a gas strut which forces the lid open.
Attention: The combination pushbutton lock is typically shipped from the factory with either no code entered
yet or “12345” and will need to be reset by the customer. Alternative pre-programmed code is
________________
2.1. Turn the OPEN lever clockwise to disengage the latch mechanism and pull the lid open while holding the OPEN
lever clockwise. Releasing the lever before pulling the lid open will allow the latch to re-engage preventing the lid
from opening.
Instructions for securing the Tuffy Lock-box to the vehicle
1.1. Open the lid.
1.2. Secure one end of the cable to an adequate anchor point in the vehicle, by creating a loop in the cable(See
Figure 2).
1.3. Place the other cable end into the notch in the cable anchor(located just behind the hinge on the left side of the
box. (See Figure 1)
1.4. Lift the cable loop so that the pinched end of the cable loop slips over the front side of the cable anchor.
(See Figure 1)
1.5. Route the cable through the notch in the side of the box(See Figure 2), and close the lid.
Figure 1
(RIGHT SIDE PANEL REMOVED FOR CLARITY)
QC CHECK
VISUAL INSPECTION
RUBBER SEAL
CORRECT KEY & COMBO CODES
PUSHBUTTON LOCK TEST
COMBO LOCK TEST
LATCH TEST
GAS SPRING TEST
FOAM FINISH KIT INSPECTION
UNLOCKED WITH KEY INSIDE
QC INSPECTOR INITIALS ____________
STEP 1.3
STEP 1.4
