See figure 3-37, See figure 3-38 – TeeJet GuideLine SmartPad II User Manual
Page 83
SmartPad II
Software Version 4.02
Chapter 3 - Real-Time Guidance
3-29
Lightbar Setup
Figure 3-37: Swath Display Mode
Figure 3-38: Vehicle Display Mode
Center LED stack equals current
guideline.
Moving LED represents the vehicle
position.
Moving LED represents the
current guideline.
Center LED stack represents
the vehicle.
