TeeJet CenterLine v1.05 User Manual
Page 29
CenterLine
Software Version 1.05
Figure 24: Setting the Steer Bar Option
Setting
Description
Off
The LEDs, representing the vehicle track in relation to the current guideline, are
shown as a single LED.
On
The LEDs, representing the vehicle track in relation to the current guideline, are
shown as a solid bar.
Table 9: Steer Bar Settings
CenterLine
CenterLine Setup
23
