Centerline kit with rx 360p waas dgps receiver, Centerline, 5 amp centerline wireless remote – TeeJet CenterLine v1.05 User Manual
Page 16: Centerline lightbar to battery
CenterLine
Software Version 1.05
CenterLine Kit with RX 360p WAAS DGPS Receiver
CenterLine
GPS Data Cable
16'
CenterLine
Power Cable
12'
RX 360p
GPS Receiver
Power Cable
12'
Bat
Acc
5 Amp
CenterLine
Wireless Remote
CenterLine
CenterLine Lightbar
To
Battery
S
e
n
s
e
Boom Sense -
+12V when booms are ON
Ignition Sense -
+12V when ignition is ON
UP
DOWN
MENU
ESC
BRIGHT
DIM
CenterLine
CenterLine
CenterLine
Figure 7: CenterLine Kit with RX360p WAAS DGPS Receiver
CenterLine
CenterLine Product Kits
10
