Centerline with rx 400p dgps receiver, Centerline, 5 amp centerline wireless remote – TeeJet CenterLine v1.05 User Manual
Page 18: Centerline lightbar to battery, Software version 1.05
CenterLine
Software Version 1.05
CenterLine with RX 400p DGPS Receiver
Bat
CenterLine
GPS Data Cable
15'
CenterLine
Power Cable
12'
Acc
5 Amp
CenterLine
Wireless Remote
CenterLine
CenterLine Lightbar
To
Battery
S
en
se
Boom Sense -
+12V when booms are ON
Ignition Sense -
+12V when ignition is ON
UP
DOW
N
MEN
U
ESC
BRIGHT
DIM
CenterLine
CenterLine
CenterLine
Power Cable
12'
RX 400p
GPS Receiver
& Antenna
Inline Fuse
11/2 Amp
+
Red
-
Blk
Flying Leads
ENTER
High Accuracy
Differential GPS Receiver
Midwest Technologies, Inc.
Lat 5100.120 N+
Lon 11202.250 WH
MID-TECH
RX 400p
RX 400p
Power lead
not used
Figure 9: CenterLine with RX 400p DGPS Receiver
CenterLine
CenterLine Product Kits
12
