Specifications – StarTech.com SV1108IPPWEU User Manual
Page 182

Instruction Manual
175
Specifications
SV1108IPEXT
SV1108IPPOW
KVM Ports
1
Console Connectors
(w/ included cable
connected)
1 x VGA Male
2 x USB type A Female
2 x PS/2 Female
PC Connectors
1 x VGA Male
1 x USB type A Male
2 x PS/2 Male
Other Connectors
1 x DB9 Serial
1 x DB9 Serial
1 x IEC320 C14 Inlet
1 x IEC320 C13 Outlet
LEDs
3 (Power, Link,
10/100Mbps)
4 (Power, Power Outlet,
Link, 10/100Mbps)
Max Resolution
1600x1200 @ 60Hz
Audio Support
No
Security
SSL, IP/Mac Filtering, 56-bit DES, 168-bit 3DES, 256-bit
AES, 128-bit RC4
Supported Protocols
RADIUS, LDAP, LDAPS, Active Directory, TCP/IP, HTTP,
HTTPS, UDP, DHCP, SSL, ARP, DNS, ICMP, CHAP, PPP
Cascadable
No
Rack Mountable
Yes
Enclosure Material
Metal
Power Consumption
6.3 W
Operating Temp.
0°C to 50°C (32°F to 122°F)
Storage Temp.
-20°C to 60°C (-4°F to 140°F)
Humidity
0~80% RH (Non-Condensing)
Dimensions (LxWxH)
200x81x25 mm
308x81x42 mm
Weight
490g
860g
