StarTech.com SV1108IPPWEU User Manual
Page 107

Instruction Manual
100
Smart Card Reader
The smart card reader function allows a reader plugged into a local client computer’s
USB port to be redirected, and appear as if it were plugged into the remote server.
One purpose of smart cards (Common Access Cards, for example), is to allow
authentication to the remote server from the local client.
When a smart card reader is connected to the local client computer, an entry for it
appears when you bring up the Virtual Media dialog box and click Add:
Make your selection; then click Mount to complete the redirection.
NOTE: If you mount a smart card reader, you cannot mount any other virtual media
device. If any virtual media devices are already mounted, you must unmount them
before you can mount the smart card reader.
Zoom
The Zoom icon controls the zoom factor for the remote view window.
Setting
Description
100%
Sizes and displays the remote view window
at 100%.
75%
Sizes and displays the remote view window
at 75%.
50%
Sizes and displays the remote view window
at 50%
25%
Sizes and displays the remote view window
at 25%.
1:1
Sizes and displays the remote view window
at 100%. The difference between this setting
and the 100% setting is that when the
remote view window is resized its contents
don’t resize – they remain at the size they
were. To see any objects that are outside of
the viewing area move the mouse to the
window edge, to have the screen scroll.
