Before You Begin Installing
151142 2-3
* Regulated/special application when used for releasing.
Table 2-1: Terminal Strip Description and Electrical Ratings
Terminal # and Label Description
Rating
Voltage Current
1 L AC input (hot)
120/240 VAC,
50/60 Hz 2.7 A
1.4 A
2 G Earth ground N/A N/A
3 N AC input (neutral)
120/240 VAC,
50/60 Hz 2.7 A
1.4 A
4 X
I/O 6* Flexput™ Circuit 24 VDC
3.0 A Notification Circuits
5 O 100 mA Initiation Circuits
6 X
I/O 5* Flexput™ Circuit 24 VDC
3.0 A Notification Circuits
7 O 100 mA Initiation Circuits
8 X
I/O 4* Flexput™ Circuit 24 VDC
3.0 A Notification Circuits
9 O
100 mA
Initiation Circuits
10 X
I/O 3* Flexput™ Circuit 24 VDC
3.0 A Notification Circuits
11 O 100 mA Initiation Circuits
12 X
I/O 2* Flexput™ Circuit 24 VDC
3.0 A Notification Circuits
13 O 100 mA Initiation Circuits
14 X
I/O 1* Flexput™ Circuit 24 VDC
3.0 A Notification Circuits
15 O 100 mA Initiation Circuits
16 B
SBUS OUT
SBUS communication 5 VDC 100 mA
17 A
18 +
SBUS power 24 VDC 1.0 A
19 -
20 B
SBUS IN Used for Class A installations
21 A
22 +
23 -
24 N.C.
RELAY 2 General Purpose Relay 2 24 VDC 2.5 A 25 C
26 N.O.
27 N.C.
RELAY 1 General Purpose Relay 1 24 VDC 2.5 A 28 C
29 N.O.
30 B
SBUS IN/
OUT
5895XL communication with
main panel or to controlling
5895XL if daisy-chained
5 VDC 100 mA
31 A
32 +
MAIN
5895XL SBUS power (from
5820XL)
24 VDC 10 mA
33 -
