Reznor ACUB Parts Manuals - Manual (Page 8)

Form P-CAUA, P/N 271166 R2, Page 8
Code 45 - MOTOR Code 46 - Starter OVERLOAD Code 47 - STARTER
Type HP
Reznor
P/N
Mfr fla volt ph Service
Factor
Power
Factor EFF %
o.l.
min
o.l.
max
GE #
Reznor
P/N
Contactor
Reznor
P/N
TEFC 0.5 159184 AOS-C613 3.5 208 1 2.50 4.10 RTA1-K 151190 CL00A310T-L 151150
TEFC 0.5 159184 AOS-C613 3.6 240 1 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
TEFC 0.5 16077 AOS-H274 2.3 208 3 1 59.5 74.80 1.80 2.70 RTA1-J 151189 CL00A310T-L 151150
TEFC 0.5 16077 AOS-H274 2 240 3 1 59.5 74.80 1.80 2.70 RTA1-J 151189 CL00A310T-S 151147
TEFC 0.5 16077 AOS-H274 1 480 3 1 59.5 74.80 0.65 1.10 RTA1-F 151186 CL00A310T-S 151147
TEFC 0.5 105568 AOS-H276 0.7 575 3 1.15 76.4 77 0.65 1.10 RTA1-F 151186 CL00A310T-S 151147
TEFC 0.75 115860 AOS-F353 5.4 208 1 1 4.00 6.30 RTA1-L 151191 CL00A310T-L 151150
TEFC 0.75 115860 AOS-F353 5.5 240 1 1 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
TEFC 0.75 20371 AOS-H580 2 208 3 1 73.5 81.10 1.80 2.70 RTA1-J 151189 CL00A310T-L 151150
TEFC 0.75 20371 AOS-H580 2.2 240 3 1 73.5 81.10 1.80 2.70 RTA1-J 151189 CL00A310T-S 151147
TEFC 0.75 20371 AOS-H580 1.1 480 3 1 73.5 81.10 1.00 1.50 RTA1-G 151187 CL00A310T-S 151147
TEFC 0.75 105569 AOS-H461 0.8 575 3 1.15 78.3 82 0.65 1.10 RTA1-F 151186 CL00A310T-S 151147
TEFC 1.0 174993 AOS-159105 6 240 1 1.15 5.50 8.50 RTA1-M 151192 CL00A310T-S 151147
TEFC 1.0 16080 AOS-H524 3.3 208 3 1 74.4 80.20 2.50 4.10 RTA1-K 151190 CL00A310T-L 151150
TEFC 1.0 16080 AOS-H524 3.4 240 3 1 74.4 80.20 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
TEFC 1.0 16080 AOS-H524 1.7 480 3 1 74.4 80.20 1.30 1.90 RTA1-H 151188 CL00A310T-S 151147
TEFC 1.0 105570 AOS-H525 1.4 575 3 1.15 71.6 80.40 1.00 1.50 RTA1-G 151187 CL00A310T-S 151147
TEFC 1.5 94347 AOS-C686 9.5 208 1 8.00 12.00 RTA1-N 151193 CL00A310T-L 151150
TEFC 1.5 94347 AOS-C686 8.2 240 1 8.00 12.00 RTA1-N 151193 CL00A310T-S 151147
TEFC 1.5 101286 AOS-H535 4.3 208 3 1 80.9 82.40 4.00 6.30 RTA1-L 151191 CL00A310T-L 151150
TEFC 1.5 101286 AOS-H535 4.4 240 3 1 80.9 82.40 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
TEFC 1.5 101286 AOS-H535 2.2 480 3 1 80.9 82.40 1.80 2.70 RTA1-J 151189 CL00A310T-S 151147
TEFC 1.5 105665 AOS-E127 1.6 575 3 1.15 85.7 84 1.30 1.90 RTA1-H 151188 CL00A310T-S 151147
TEFC 2.0 205881 L3516TM 8.3 240 1 1.15 99 78 10.00 16.00 RTA1-P 151194 CL01A310T-S 151152
TEFC 2.0 158165 B-M3587T 6.3 208 3 5.50 8.50 RTA1-M 151192 CL00A310T-L 151150
TEFC 2.0 158165 B-M3587T 5.8 240 3 4.00 6.30 RTA1-L 151191 CL00A310T-S 151147
TEFC 2.0 158165 B-M3587T 2.9 480 3 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
TEFC 2.0 158166 B-M3587T-5 2.2 575 3 1.90 2.70 RTA1-J 151189 CL00A310T-S 151147
TEFC 3.0 111564 AOS-K222 15 240 1 1 10.00 16.00 RTA1-P 151194 CL02A310T-S 151157
TEFC 3.0 159330 B - M3559T 7.9 208 3 5.50 8.50 RTA1-M 151192 CL00A310T-L 151150
TEFC 3.0 159330 B - M3559T 7.2 240 3 5.50 8.50 RTA1-M 151192 CL00A310T-S 151147
TEFC 3.0 159330 B - M3559T 3.6 480 3 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
TEFC 3.0 158168 B-M3660T-5 3 575 3 2.50 4.10 RTA1-K 151190 CL00A310T-S 151147
TEFC 5.0 111567 AOS-K223 20.2 240 1 1 21.00 26.00 RTA1-U 151198 CL04A310M-S 151166
TEFC 5.0 155048 B-3663T 12.8 208 3 14.50 18.00 RTA1-S 151196 CL01A310T-L 151155
TEFC 5.0 155048 B-3663T 11.8 240 3 10.00 16.00 RTA1-P 151194 CL01A310T-S 151152
TEFC 5.0 155048 B-3663T 5.9 480 3 4.00 6.30 RTA1-L 151191 CL01A310T-S 151152
TEFC 5.0 158170 B-3663T-5 4.8 575 3 4.00 6.30 RTA1-L 151191 CL01A310T-S 151152
Code 48 - Replacement Holding Coils for Starter Overloads
Voltage GE #
Reznor
P/N
For Use with
Contactors
Beginning
with GE#
Voltage GE #
Reznor
P/N
For Use with
Contactors
Beginning
with GE#
Voltage GE # Reznor
P/N
For Use with
Contactors
Beginning
with GE#
24 LB1A-C 151280
CL00; CL01;
CL02; CL25
24 LB3A-C 151286
CL04; CL45
208 LB4A-L 151292
CL06; CL07;
CL08; CL09;
120 LB1A-J 151281 120 LB3A-J 151287 230 LB4A-S 151293
208 LB1A-L 151282 208 LB3A-L 151288 460 LB4A-U 151294
230 LB1A-S 151283 230 LB3A-S 151289
460 LB1A-U 151284 460 LB3A-U 151290
575 LB1A-Y 151285 575 LB3A-Y 151291
Replacement Belt-Driven Blower Motors and Starters (cont’d)
