Reznor ACUB Parts Manuals - Manual (Page 10)

Form P-CAUA, P/N 271166 R2, Page 10
Drive Table for OPEN MOTORS (cont’d)
CAUA
Size
MOTOR
AM Nos. (See Key page 8.)
CODE 50 - Motor
Pulley
CODE 51 - Blower
Pulley
CODE 52 -
Belt
HP
Opt
No.
Voltage (See
Key page 8.)
P/N
Mfr
No.
Bore P/N Mfr No. Bore P/N
Mfr
No.
300
3 AL9 AK2,3 AM15, AM16, AM17, AM18, AM19, AM20 105476 1VL44 5/8” 111609 AK99 1” 88558 A50
3 AL9 AK5,6,7,8 AM15, AM16, AM17, AM18, AM19, AM20 106758 1VL44 7/8” 111609 AK99 1” 88558 A50
5 AL10 AK2,3 AM20, AM21, AM22, AM23 111681 1VP50 1-1/8” 111609 AK99 1” 50475 A49
5 AL10 AK5,6,7,8 AM20, AM21, AM22, AM23 37451 1VM50 7/8” 111609 AK99 1” 50475 A49
350
3/4 AL5 AK2,3,5,6,7 AM2, AM3, AM4 13580 1VL34 5/8” 19111 AK84 1” 50476 A58
1 AL6 AK2,3,5,6,7 AM4, AM5, AM6, AM7 13580 1VL34 5/8” 18797 AK64 1” 16131 A54
1 AL6 AK8 AM4, AM5, AM6, AM7 110125 1VP34 7/8” 18797 AK64 1” 16131 A54
1-1/2 AL7 AK2,3,5,6,7 AM6, AM7, AM8, AM9, AM10 13580 1VL34 5/8” 115716 AK59 1” 16130 A53
1-1/2 AL7 AK8 AM6, AM7, AM8, AM9, AM10 110125 1VP34 7/8” 115716 AK59 1” 16130 A53
2 AL8 AK2,3,5,6,7,8
AM7, AM8, AM9 106758 1VL44 7/8” 19111 AK84 1” 92402 A59
AM10, AM11, AM12 106758 1VL44 7/8” 135279 AK66 1” 16133 A56
3 AL9 AK2,3
AM8, AM9, AM10 7962 1VL40 5/8” 50520 AK134 1” 92408 A68
AM11, AM12, AM13, AM14 7962 1VL40 5/8” 16153 AK104 1” 16137 A62
3 AL9 AK5,6,7,8
AM8, AM9, AM10 106748 1VL40 7/8” 50520 AK134 1” 92408 A68
AM11, AM12, AM13, AM14 106748 1VL40 7/8” 16153 AK104 1” 16137 A62
5 AL10 AK2,3
AM13, AM14, AM15, AM16 111681 1VP50 1-1/8” 50520 AK134 1” 16558 A69
AM17, AM18, AM19 110151 1VP44 1-1/8” 111609 AK99 1” 16137 A62
5 AL10 AK5,6,7,8
AM13, AM14, AM15, AM16 37451 1VM50 7/8 50520 AK134 1” 16558 A69
AM17, AM18, AM19 106758 1VL44 7/8 111609 AK99 1” 16137 A62
400
3/4 AL5 AK2,3,5,6,7 AM3 13580 1VL34 5/8” 19111 AK84 1” 50476 A58
1 AL6 AK2,3,5,6,7 AM4, AM5, AM6, AM7 13580 1VL34 5/8” 18797 AK64 1” 16131 A54
1 AL6 AK8 AM4, AM5, AM6, AM7 110125 1VP34 7/8” 18797 AK64 1” 16131 A54
1-1/2 AL7 AK2,3,5,6,7 AM6, AM7, AM8, AM9, AM10 13580 1VL34 5/8” 115716 AK59 1” 16130 A53
1-1/2 AL7 AK8 AM6, AM7, AM8, AM9, AM10 110125 1VP34 7/8” 115716 AK59 1” 16130 A53
2 AL8 AK2,3,5,6,7,8
AM7, AM8, AM9 106758 1VL44 7/8” 19111 AK84 1” 92402 A59
AM10, AM11 106758 1VL44 7/8” 135279 AK66 1” 16133 A56
3 AL9 AK2,3
AM8, AM9, AM10 7962 1VL40 5/8” 50520 AK134 1” 92408 A68
AM11, AM12, AM13, AM14, AM15 7962 1VL40 5/8” 16153 AK104 1” 16137 A62
3 AL9 AK5,6,7,8
AM8, AM9, AM10 106748 1VL40 7/8” 50520 AK134 1” 92408 A68
AM11, AM12, AM13, AM14, AM15 106748 1VL40 7/8” 16153 AK104 1” 16137 A62
5 AL10 AK2,3
AM12, AM14, AM15, AM16 111681 1VP50 1-1/8” 50520 AK134 1” 16558 A69
AM17, AM18, AM19 110151 1VP44 1-1/8” 111609 AK99 1” 16137 A62
5 AL10 AK5,6,7,8
AM12, AM14, AM15, AM16 37451 1VM50 7/8 50520 AK134 1” 16558 A69
AM17, AM18, AM19 106758 1VL44 7/8 111609 AK99 1” 16137 A62
Drive Table for TEFC MOTORS - Model CAUA
CAUA
Size
MOTOR
AM Nos. (See Key page 8.)
CODE 50 - Motor
Pulley
CODE 51 - Blower
Pulley
CODE 52 -
Belt
HP
Opt
No.
Voltage (See
Key page 8.)
P/N
Mfr
No.
Bore P/N
Mfr
No. Bore P/N
Mfr
No.
150
1/3 AL20 AK2,3,5,6,7 AM1, AM2, AM3, AM4
4074 1VL34 1/2” 19111 AK84 1” 50472 A45
AM5, AM6 4074 1VL34 1/2” 18797 AK64 1” 101412 A42
1/2 AL21 AK2,3,5,6,7,8 AM5, AM6, AM7, AM8 13580 1VL34 5/8” 18797 AK64 1” 101412 A42
3/4 AL22 AK2,3,5,6,7,8 AM7, AM8, AM9, AM10, AM11 13580 1VL34 5/8” 135202 AK54 1” 16019 A40
1 AL23 AK3,5,6,7,8 AM10, AM11, AM12, AM13 13580 1VL34 5/8” 105481 AK46 1” 105493 A39
1-1/2 AL24 AK2,3,5,6,7 AM11, AM12, AM13, AM14, AM15, AM16 7962 1VL40 5/8” 135202 AK54 1” 101412 A42
1-1/2 AL24 AK8 AM11, AM12, AM13, AM14, AM15, AM16 106748 1VL40 7/8” 135202 AK54 1” 101412 A42
2 AL25 AK3,5,6,7,8 AM17 106748 1VL40 7/8” 135200 AK51 1” 50500 A41
200
1/3 AL20 AK2,3,5,6,7 AM3 4074 1VL34 1/2” 19111 AK84 1” 50472 A45
1/2 AL21 AK2,3,5,6,7,8 AM5, AM6, AM7 13580 1VL34 5/8” 105483 AK69 1” 50470 A43
3/4 AL22 AK2,3,5,6,7,8 AM6, AM7, AM8, AM9, AM10 13580 1VL34 5/8” 105482 AK56 1” 50500 A41
1 AL23 AK3,5,6,7,8 AM7, AM8, AM9, AM10, AM11 13580 1VL34 5/8” 105482 AK56 1” 50500 A41
1-1/2 AL24 AK2,3,5,6,7 AM9, AM10, AM11, AM12, AM13, AM14 7962 1VL40 5/8” 115716 AK59 1” 50470 A43
1-1/2 AL24 AK8 AM9, AM10, AM11, AM12, AM13, AM14 106748 1VL40 7/8” 115716 AK59 1” 50470 A43
2 AL25 AK3,5,6,7,8 AM13, AM14, AM15, AM16 106748 1VL40 7/8” 135202 AK54 1” 101412 A42
Components of Belt Drives (cont’d)
