Form P-CAUA, P/N 271166 R2, Page 2
Serial No.
Sample: BLJ 78 Q3 N 12345
Elements:
1 2 3 4 5
Key: 1 = Date of Manufacture (see table below)
2 = Type of ignition system (See Form P-VALVES)
3 = Identifies the gas valve (See Form P-VALVES)
4 = Type of gas (N, natural gas; L, propane)
5 = Consecutive number of heater manufactured
Model No.
Sample: CAUA 200 __ __
Model Size Series* Suffix**
*Currently blank. When the Model CAUA Series is recertified,
a serial number will be added to the Model No.
** Model No. Suffixes: -S = Stainless Steel Heat Exchanger
-2 = Two-Stage Gas Valve
-H = Factory built for high altitude
Rating Plate Sample Rating Plate Key:
AA/A = Date of ANSI Standard
AA 1 /A 1 = Date of CGA Standard
B = Model No.
C = Month/Year of Manufacture
D = Blower Motor HP
E = Volts, Phase, and
Maximum Input Amps
F = Natural Gas or Propane
H/I = Elevation (Feet/Meters)
J = Orifice Size
S = BTU Input Sea Level
K = BTU Input Altitude Adjusted
T = BTU Thermal Output Sea Level
L = BTU Thermal Output Altitude
Adjusted
U = BTU Minimum Input Sea Level (with
2-stage gas valve, -2 Model)
M = BTU Minimum Input Altitude
Adjusted (with 2-stage gas valve,
-2 Model)
N = Manifold Pressure (3.5 w.c. Natural
Gas; 10 w.c. Propane)
O = Minimum Gas Supply Pressure
(5.0 w.c. Natural Gas; 11.0 w.c.
Propane)
W = SCFM Airflow
X = inches w.c. Static Pressure
Y = Drive No.
Rating Plate
and Serial No.
First Element of the
Serial Number - Date of
Manufacture
Year Jan Feb Mar Apr May June July Aug Sept Oct Nov Dec
1998 AXA AXB AXC AXD AXE AXF AXG AXH AXI AXJ AXK AXL
1999 AYA AYB AYC AYD AYE AYF AYG AYH AYI AYJ AYK AYL
2000 AZA AZB AZC AZD AZE AZF AZG AZH AZI AZJ AZK AZL
2001 BAA BAB BAC BAD BAE BAF BAG BAH BAI BAJ BAK BAL
2002 BBA BBB BBC BBD BBE BBF BBG BBH BBI BBJ BBK BBL
2003 BCA BCB BCC BCD BCE BCF BCG BCH BCI BCJ BCK BCL
2004 BDA BDB BDC BDD BDE BDF BDG BDH BDI BDJ BDK BDL
2005 BEA BEB BEC BED BEE BEF BEG BEH BEI BEJ BEK BEL
2006 BFA BFB BFC BFD BFE BFF BFG BFH BFI BFJ BFK BFL
2007 BGA BGB BGC BGD BGE BGF BGG BGH BGI BGJ BGK BGL
2008 BHA BHB BHC BHD BHE BHF BHG BHH BHI BHJ BHK BHL
2009 BIA BIB BIC BID BIE BIF BIG BIH BII BIJ BIK BIL
2010 BJA BJB BJC BJD BJE BJF BJG BJH BJI BJJ BJK BJL
2011 BKA BKB BKC BKD BKE BKF BKG BKH BKI BKJ BKK BKL
2012 BLA BLB BLC BLD BLE BLF BLG BLH BLI BLJ BLK BLL
2013 BMA BMB BMC BMD BME BMF BMG BMH BMI BMJ BMK BML
2014 BNA BNB BNC BND BNE BNF BNG BNH BNI BNJ BNK BNL
2015 BOA BOB BOC BOD BOE BOF BOG BOH BOI BOJ BOK BOL
2016 BPA BPB BPC BPD BPE BPF BPG BPH BPI BPJ BPK BPL
2017 BQA BQB BQC BQD BQE BQF BQG BQH BQI BQJ BQK BQL
REZNOR
MERCER, PA. USA 16137
MADE IN MEXICO
UNIT HEATER
CATEGORY III
ANSI Z83.8 [ AA ] - [ A ] CSA 2.6 [ AA' ] - [ A' ] UNIT HEATER
MODEL [ B ] [ C ]
SERIAL NO. [ D ] HP
[ E ] VOLTS [ E ] PH [ E ] HZ MAXIMUM TOTAL INPUT [ E ] AMPS
TYPE OF GAS: [ F ]
ORIFICE SIZE [ J ] DRILL HAS BEEN FACTORY ADJUSTED
FOR USE AT [ H ] FEET [ I ] METERS OF ALTITUDE.
SEA
LEVEL ALT. ADJUSTED
NORMAL INPUT [ S ] [ K ]BTU/HR.
THERMAL OUTPUT CAPACITY [ T ] [ L ]BTU/HR.
MINIMUM INPUT (-2 MODELS) [ U ] [ M ]BTU/HR.
NORMAL MANIFOLD PRESSURE [ N ] IN.W.C.
MIN. PERMISSIBLE GAS SUPPLY PRESSURE
FOR PURPOSE OF INPUT ADJUSTMENT
[ O ] IN.W.C.
EQUIPPED FOR OPERATION AT AN AIRFLOW OF [ W ] SCFM
AGAINST A STATIC PRESSURE OF
[ X ] IN. W.C.
DRIVE NO. [ Y ]
CLEARANCES TO COMBUSTIBLE CONSTRUCTION: TOP-3", FLUE
CONNECTION-6", LEFT SIDE-0", RIGHT SIDE-0", BOTTOM-0", REAR 0"
THIS UNIT MAY BE USED WITH DUCTS.
FILTERS, WHEN USED, MUST BE INSTALLED EXTERNAL TO THE
FURNACE CASING.
